İlk izlenimler: Lenovo ThinkPad T480s (i5, WQHD) Laptop

Yeni nesil. Lenovo, ThinkPad T480s modelini yeni bir kasa ile güncelleyip ThinkPad X1 Carbon ile arasındaki farkı kapatmaya çalışıyor. Intel'in en son quad-core işlemcisi de bu güncellemeye dahil.

Andreas Osthoff, 👁 Andreas Osthoff, Published 03/04/2018 🇺🇸 🇩🇪 ...

Lenovo ThinkPad T480s-20L8S02D00 (ThinkPad T480s Seri)

İşlemci

Intel Core i5-8250U 4 x 1.6 - 3.4 GHz, Kaby Lake Refresh

Grafik kartı

Intel UHD Graphics 620, Çekirdek: 1100 MHz

Bellek

8 GB

, DDR4-2400, soldered, 1 empty slot

Görüntü

14.00 inç 16:9, 2560 x 1440 pixel 210 PPI, LP140QH2-SPB1, IPS, parlak: hayır

Anakart

Intel Kaby Lake-U iHDCP 2.2 Premium PCH

Harddisk

Samsung SSD PM981 MZVLB512HAJQ, 512 GB

Ses kartı

Intel Kaby Lake-U/Y PCH - High Definition Audio

Bağlantılar

3 USB 3.0, 1 USB 3.1 Gen2, 1 Thunderbolt, 1 HDMI, 1 DisplayPort, 1 Kensington Lock, 1 Docking Station Portu, Ses çıkışları: 3.5 mm stereo jack, Kart okuyucular: 4-in-1 (MMC, SD, SDHC, SDXC), 1 SmartCard, 1 Parmak izi okuyucu, TPM 2.0

Network

Intel Ethernet Connection I219-V (10/100/1000MBit/s), Intel Dual Band Wireless-AC 8265 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 4.2

Boyut

yükseklik x genişlik x derinlik (mm): 18.45 x 331 x 226.8

Batarya

57 Wh Lithium-Polymer, Batarya kullanım süresi (üreticiye göre): 12.8 h

Camera

Webcam: 720p HD, ThinkShutter

Ek özellikler

Hoparlörler: Stereo (2x 1W), Klavye: Chiclet, Klavye ışığı: evet, 65W PSU, 36 Ay Garanti

Ağırlık

1.367 kg, Güç kaynağı: 356 g

Fiyat

1259 Euro

Bağlantılar

Lenovo anasayfa

Note: The manufacturer may use components from different suppliers including display panels, drives or memory sticks with similar specifications.

see all specifications

Size Comparison

HP EliteBook 840 G4-Z2V49ET ABD Lenovo ThinkPad T470-20HD002HGE Fujitsu LifeBook U747 Lenovo ThinkPad T470s-20HGS00V00 Lenovo ThinkPad T480s-20L8S02D00 Dell Latitude 7480 Lenovo ThinkPad X1 Carbon 2018-20KGS03900 DIN A4 ❌

X1 Carbon 2018 HDR (left) vs. T480s (right)

X1 Carbon 2018 HDR (top) vs. T480s (bottom)

Left side: Thunderbolt 3, USB-C 3.1 (Gen1), docking, Gigabit Ethernet, USB 3.0, HDMI 1.4b, 3.5 mm stereo jack, full-size card reader

Right side: SmartCard, USB 3.0, slot for a security lock


330 cd/m²	335 cd/m²	338 cd/m²
345 cd/m²	352 cd/m²	341 cd/m²
362 cd/m²	339 cd/m²	343 cd/m²

Parlaklığın yayılımı

LP140QH2-SPB1 tested with X-Rite i1Pro 2

Maksimum: 362 cd/m² (Nits) Ortalama: 342.8 cd/m² Minimum: 5 cd/m²
Aydınlatma: 91 %
Batarya modunda parlaklık: 351 cd/m²
Kontrast: 765:1 (Siyah: 0.46 cd/m²)
ΔE Color 3.3 | 0.5-29.43 Ø4.91
ΔE Greyscale 5.3 | 0.5-98 Ø5.2
98% sRGB (Argyll 1.6.3 3D)
68.4% AdobeRGB 1998 (Argyll 1.6.3 3D)
74.1% AdobeRGB 1998 (Argyll 2.2.0 3D)
97.9% sRGB (Argyll 2.2.0 3D)
72.8% Display P3 (Argyll 2.2.0 3D)
Gamma: 2.22

Download ICC Dosyası (X-Rite i1Pro 2)

	Lenovo ThinkPad T480s-20L8S02D00 LP140QH2-SPB1, , 2560x1440, 14"	Lenovo ThinkPad T470s-20HGS00V00 B140QAN01.5, , 2560x1440, 14"	Lenovo ThinkPad X1 Carbon 2017-20HR006FGE LEN40AA (LP140QH2-SPB1), , 2560x1440, 14"	Lenovo ThinkPad X1 Carbon 2018-20KGS03900 B140QAN02.0, , 2560x1440, 14"	Lenovo ThinkPad T470-20HD002HGE N140HCA-EAB, , 1920x1080, 14"	HP EliteBook 840 G4-Z2V45ES ABD LGD04F3, , 2560x1440, 14"	Dell Latitude 7480 LG Philips LGD0557, , 1920x1080, 14"
Display		-5%	1%	19%	-41%	-7%	-9%
Display P3 Coverage	72.8	69 -5%	73.5 1%	87.7 20%	41.6 -43%	66.2 -9%	65.4 -10%
sRGB Coverage	97.9	95.1 -3%	98.4 1%	100 2%	61.9 -37%	94.1 -4%	92.3 -6%
AdobeRGB 1998 Coverage	74.1	69.6 -6%	74.5 1%	99.9 35%	43.06 -42%	67.2 -9%	65.8 -11%
Response Times		-11%	14%	-38%	-14%	12%	-8%
Response Time Grey 50% / Grey 80% *	38.4 ?(19.6, 18.8)	46.4 ?(20.4, 26) -21%	35.6 ?(18.4, 17.2) 7%	59.2 ?(28.4, 30.8) -54%	41.6 ?(20.4, 21.2) -8%	37.2 ?(23.6, 15.6) 3%	40.8 ?(19.2, 21.6) -6%
Response Time Black / White *	28.4 ?(15.6, 12.8)	28.8 ?(16.4, 12.4) -1%	22.4 ?(12.4, 12) 21%	34.4 ?(16.4, 18) -21%	34 ?(9.6, 24.4) -20%	22.8 ?(10.8, 12) 20%	31.2 ?(18.8, 12.4) -10%
PWM Frequency
Screen		-13%	1%	39%	-23%	-0%	11%
Brightness middle	352	327 -7%	342 -3%	578 64%	306 -13%	340 -3%	344 -2%
Brightness	343	311 -9%	337 -2%	533 55%	287 -16%	304 -11%	321 -6%
Brightness Distribution	91	88 -3%	87 -4%	84 -8%	88 -3%	81 -11%	85 -7%
Black Level *	0.46	0.25 46%	0.37 20%	0.38 17%	0.3 35%	0.32 30%	0.32 30%
Contrast	765	1308 71%	924 21%	1521 99%	1020 33%	1063 39%	1075 41%
Colorchecker dE 2000 *	3.3	6.1 -85%	3.6 -9%	1.9 42%	6.2 -88%	4.3 -30%	2.6 21%
Colorchecker dE 2000 max. *	7.3	12.2 -67%	7.7 -5%	3.8 48%	13.6 -86%	7.5 -3%	7.8 -7%
Greyscale dE 2000 *	5.3	8.8 -66%	5.8 -9%	3 43%	5.8 -9%	5.3 -0%	2.6 51%
Gamma	2.22 ^99%	2.18 ^101%	2.2 ^100%	2.14 ^103%	2.04 ^108%	2.18 ^101%	2.28 ^96%
CCT	6452 ^101%	6172 ^105%	6693 ^97%	6377 ^102%	6277 ^104%	7016 ^93%	7050 ^92%
Color Space (Percent of AdobeRGB 1998)	68.4	61.56 -10%	68.8 1%	88.8 30%	39.62 -42%	60.9 -11%	65.82 -4%
Color Space (Percent of sRGB)	98	94.88 -3%	98.5 1%	100 2%	61.44 -37%	94.2 -4%	92.27 -6%
Colorchecker dE 2000 calibrated *				0.8
Total Average (Program / Settings)		-10% / -11%	5% / 3%	7% / 25%	-26% / -25%	2% / -0%	-2% / 5%

* ... smaller is better

Cinebench R15
CPU Single 64Bit
Average of class Office (98 - 284, n=97, last 2 years)	231 Points +62%
Lenovo ThinkPad X1 Carbon 2018-20KGS03900 Intel Core i7-8550U	168 Points +17%
Lenovo ThinkPad T470s-20HGS00V00 Intel Core i7-7600U	162 Points +13%
Dell Latitude 7480 Intel Core i7-7600U	162 Points +13%
Lenovo ThinkPad T480s-20L8S02D00 Intel Core i5-8250U	143 Points
Asus ROG Strix GL702VI-WB74 Intel Core i7-7700HQ	142 Points -1%
Average Intel Core i5-8250U (81 - 147, n=97)	141.1 Points -1%
Asus GL702VM-GC102D Intel Core i7-6700HQ	134 Points -6%
Fujitsu LifeBook U747 Intel Core i5-7200U	130 Points -9%
Lenovo ThinkPad T470-20HD002HGE Intel Core i5-7200U	126 Points -12%
HP EliteBook 840 G4-Z2V49ET ABD Intel Core i5-7200U	119 Points -17%
CPU Multi 64Bit
Average of class Office (246 - 2642, n=98, last 2 years)	1577 Points +118%
Lenovo ThinkPad T480s-20L8S02D00 Intel Core i5-8250U	724 Points
Lenovo ThinkPad T480s-20L8S02D00 Intel Core i5-8250U	716 Points -1%
Asus ROG Strix GL702VI-WB74 Intel Core i7-7700HQ	723 Points 0%
Lenovo ThinkPad X1 Carbon 2018-20KGS03900 Intel Core i7-8550U	708 Points -2%
Lenovo ThinkPad X1 Carbon 2018-20KGS03900 Intel Core i7-8550U	648 Points -10%
Asus GL702VM-GC102D Intel Core i7-6700HQ	678 Points -6%
Average Intel Core i5-8250U (320 - 730, n=101)	570 Points -21%
Lenovo ThinkPad T470s-20HGS00V00 Intel Core i7-7600U	368 Points -49%
Dell Latitude 7480 Intel Core i7-7600U	343 Points -53%
Fujitsu LifeBook U747 Intel Core i5-7200U	331 Points -54%
HP EliteBook 840 G4-Z2V49ET ABD Intel Core i5-7200U	329 Points -55%
Lenovo ThinkPad T470-20HD002HGE Intel Core i5-7200U	326 Points -55%

Cinebench R15 CPU Multi 64 Bit

Batarya ömrü

WiFi Websurfing (Edge)		8h 57min
Big Buck Bunny H.264 1080p		12h 01min
Çalışırken (maksimum parlaklık)		2h 04min

	Lenovo ThinkPad T480s-20L8S02D00 i5-8250U, UHD Graphics 620, 57 Wh	Lenovo ThinkPad T470s-20HGS00V00 i7-7600U, HD Graphics 620, 51 Wh	Lenovo ThinkPad T470-20HD002HGE i5-7200U, HD Graphics 620, 48 Wh	Lenovo ThinkPad X1 Carbon 2018-20KGS03900 i5-8550U, UHD Graphics 620, 57 Wh	HP EliteBook 840 G4-Z2V49ET ABD i5-7200U, HD Graphics 620, 51 Wh	Dell Latitude 7480 i7-7600U, HD Graphics 620, 60 Wh	Fujitsu LifeBook U747 i5-7200U, HD Graphics 620, 50 Wh
Battery Runtime		-30%	-16%	-12%	-6%	34%	-26%
H.264	721	454 -37%	623 -14%	566 -21%	591 -18%		490 -32%
WiFi v1.3	537	417 -22%	438 -18%	519 -3%	571 6%	719 34%	430 -20%

In review: Lenovo ThinkPad T480s. Test model courtesy of Campuspoint.

Yeni T480s hakkındaki ilk izlenimlerimiz oldukça pozitif. Lenovo daha verimli WQHD ekranı kullanıp farkedilir şekilde batarya kullanım süresini arttırmayı başarmış.

Performans kullanımı ise ilginç bir hikayeye dönüşüyor. Core i5-8250U harika bir performans sunup, soğutma ile sıcaklık üretimi arasındaki dengeyi tutturmuş gibi. Yüzey sıcaklıkları halen farkedilir derecede yüksek olsa da X1 Carbon 2018 modelinden daha düşük. Fan sesi rahatsız edici değil. Aynı soğutma sisteminin MX 150 grafik kartı ile gelen modellerde de kullanılmasını bekleyebiliriz.
