Kısa inceleme: Dell Latitude 15 3570 Notebook

Name: Dell Latitude 15-3570
Brand: Dell

Ofiste ucuzluk. Dell orta fiyat aralığındaki yeni 15 inçlik ofis serisini sunuyor. Düşük ekran çözünürlüğünü önemsemeyen ve arayüzlerden fazla beklentisi olmayan kullanıcılar hedef grubunda.

Sven Kloevekorn, ✓ Tanja Hinum, Published 07/20/2016 🇺🇸 🇩🇪 ...

Laptop / Notebook Skylake Windows

Test device courtesy of Dell Deutschland

Download your licensed rating image as PNG / SVG

Dell Latitude 15-3570 (Latitude 3000 Seri)

İşlemci

Intel Core i5-6200U 2 x 2.3 - 2.8 GHz, Skylake

Grafik kartı

Intel HD Graphics 520, Çekirdek: 1050 MHz, shared memory, 20.19.15.4390

Bellek

8 GB

, DDR3L, 1600 MHz, single-channel

Görüntü

15.60 inç 16:9, 1366 x 768 pixel 101 PPI, LG Philips LGD04AF / 156WHU, TN LED, parlak: hayır

Anakart

Intel Skylake-U Premium PCH

Harddisk

Samsung CM871 MZNLF128HCHP, 128 GB

Ses kartı

Intel Skylake-U/Y PCH - High Definition Audio

Bağlantılar

1 USB 2.0, 2 USB 3.0, 1 VGA, 1 HDMI, 1 Kensington Lock, Ses çıkışları: combo audio in/out, 3.5 mm jack, Kart okuyucular: SD/SDHC/SDXC, Brightness Sensor

Network

Realtek RTL8168/8111 Gigabit-LAN (10/100/1000MBit/s), Atheros AR5BWB222 Wireless Network Adapter (b/g/n = Wi-Fi 4/), Bluetooth 4.1

Boyut

yükseklik x genişlik x derinlik (mm): 23.25 x 380 x 260

Batarya

65 Wh Lithium-Ion, removeable, 6 cells

İşletim sistemi

Microsoft Windows 10 Pro 64 Bit

Camera

Webcam: present

Ek özellikler

Hoparlörler: stereo, Klavye: chiclet, Klavye ışığı: hayır, 24 Ay Garanti

Ağırlık

2.06 kg, Güç kaynağı: 236 g

Fiyat

629 EUR

Bağlantılar

Dell anasayfa
Dell notebook kısmı

Note: The manufacturer may use components from different suppliers including display panels, drives or memory sticks with similar specifications.

see all specifications

Right: Power-in, vent, HDMI, 2 x USB 3.0, audio in /out


221 cd/m²	199 cd/m²	214 cd/m²
225 cd/m²	202 cd/m²	208 cd/m²
225 cd/m²	197 cd/m²	207 cd/m²

Parlaklığın yayılımı

LG Philips LGD04AF / 156WHU tested with X-Rite i1Pro 2

Maksimum: 225 cd/m² (Nits) Ortalama: 210.9 cd/m² Minimum: 9.6 cd/m²
Aydınlatma: 88 %
Batarya modunda parlaklık: 206 cd/m²
Kontrast: 326:1 (Siyah: 0.62 cd/m²)
ΔE Color 12.35 | 0.5-29.43 Ø4.92
ΔE Greyscale 13.46 | 0.5-98 Ø5.2
61% sRGB (Argyll 1.6.3 3D)
39% AdobeRGB 1998 (Argyll 1.6.3 3D)
41.96% AdobeRGB 1998 (Argyll 2.2.0 3D)
61.1% sRGB (Argyll 2.2.0 3D)
40.61% Display P3 (Argyll 2.2.0 3D)
Gamma: 2.44

Download ICC Dosyası (X-Rite i1Pro 2)

	Dell Latitude 15-3570	Lenovo ThinkPad L560-20F10026GE	HP ProBook 450 G3	Lenovo ThinkPad E550-20DF00CNGE
Display		-4%	-6%	-2%
Display P3 Coverage	40.61	39 -4%	38.1 -6%	39.84 -2%
sRGB Coverage	61.1	58.3 -5%	57.3 -6%	59.3 -3%
AdobeRGB 1998 Coverage	41.96	40.33 -4%	39.37 -6%	41.2 -2%
Response Times		9%	7%
Response Time Grey 50% / Grey 80% *	37 ?(13, 24)	39.2 ?(18.8, 20.4) -6%	41.2 ?(22.4, 18.8) -11%
Response Time Black / White *	37 ?(20, 17)	28 ?(12.4, 15.6) 24%	28 ?(10, 18) 24%
PWM Frequency
Screen		35%	14%	9%
Brightness middle	202	262 30%	211 4%	195 -3%
Brightness	211	250 18%	214 1%	188 -11%
Brightness Distribution	88	92 5%	91 3%	90 2%
Black Level *	0.62	0.29 53%	0.43 31%	0.46 26%
Contrast	326	903 177%	491 51%	424 30%
Colorchecker dE 2000 *	12.35	8.49 31%	9.25 25%	9.92 20%
Colorchecker dE 2000 max. *	19.9	17.99 10%
Greyscale dE 2000 *	13.46	8.11 40%	9.83 27%	10.06 25%
Gamma	2.44 ^90%	2.37 ^93%	2.82 ^78%	2.37 ^93%
CCT	15217 ^43%	6300 ^103%	10890 ^60%	11552 ^56%
Color Space (Percent of AdobeRGB 1998)	39	37.07 -5%	36.4 -7%	38 -3%
Color Space (Percent of sRGB)	61	57.94 -5%	57.3 -6%	59.3 -3%
Total Average (Program / Settings)		13% / 24%	5% / 9%	4% / 6%

* ... smaller is better

Display Response Times

ℹ

Display response times show how fast the screen is able to change from one color to the next. Slow response times can lead to afterimages and can cause moving objects to appear blurry (ghosting). Gamers of fast-paced 3D titles should pay special attention to fast response times.

↔ Response Time Black to White
37 ms ... rise ↗ and fall ↘ combined	↗ 20 ms rise
37 ms ... rise ↗ and fall ↘ combined	↘ 17 ms fall
The screen shows slow response rates in our tests and will be unsatisfactory for gamers. In comparison, all tested devices range from 0.1 (minimum) to 240 (maximum) ms. » 95 % of all devices are better. This means that the measured response time is worse than the average of all tested devices (21 ms).
↔ Response Time 50% Grey to 80% Grey
37 ms ... rise ↗ and fall ↘ combined	↗ 13 ms rise
37 ms ... rise ↗ and fall ↘ combined	↘ 24 ms fall
The screen shows slow response rates in our tests and will be unsatisfactory for gamers. In comparison, all tested devices range from 0.165 (minimum) to 636 (maximum) ms. » 49 % of all devices are better. This means that the measured response time is worse than the average of all tested devices (32.9 ms).

Screen Flickering / PWM (Pulse-Width Modulation)

ℹ

To dim the screen, some notebooks will simply cycle the backlight on and off in rapid succession - a method called Pulse Width Modulation (PWM) . This cycling frequency should ideally be undetectable to the human eye. If said frequency is too low, users with sensitive eyes may experience strain or headaches or even notice the flickering altogether.

Screen flickering / PWM not detected

In comparison: 53 % of all tested devices do not use PWM to dim the display. If PWM was detected, an average of 8746 (minimum: 5 - maximum: 343500) Hz was measured.

Cinebench R15
CPU Multi 64Bit
Lenovo ThinkPad L560-20F10026GE Intel Core i5-6200U	290 Points 0%
Dell Latitude 15-3570 Intel Core i5-6200U	290 Points
HP ProBook 450 G3 Intel Core i5-6200U	288 Points -1%
Lenovo ThinkPad E550-20DF00CNGE Intel Core i7-5500U	282 Points -3%
CPU Single 64Bit
Lenovo ThinkPad E550-20DF00CNGE Intel Core i7-5500U	123 Points +6%
HP ProBook 450 G3 Intel Core i5-6200U	116 Points 0%
Lenovo ThinkPad L560-20F10026GE Intel Core i5-6200U	116 Points 0%
Dell Latitude 15-3570 Intel Core i5-6200U	116 Points

Cinebench R15 CPU Single 64Bit

116 Points

Cinebench R15 CPU Multi 64Bit

290 Points

Yardım

... kıyaslama

PCMark 8
Home Score Accelerated v2
Lenovo ThinkPad E550-20DF00CNGE Radeon R7 M265, 5500U, WDC Slim WD10SPCX-22HWST0	3960 Points +19%
Dell Latitude 15-3570 HD Graphics 520, 6200U, Samsung CM871 MZNLF128HCHP	3337 Points
HP ProBook 450 G3 HD Graphics 520, 6200U, Seagate ST500LM021-1KJ15	2910 Points -13%
Lenovo ThinkPad L560-20F10026GE HD Graphics 520, 6200U, WDC Slim WD10SPCX-21KHST0	2886 Points -14%
Work Score Accelerated v2
Dell Latitude 15-3570 HD Graphics 520, 6200U, Samsung CM871 MZNLF128HCHP	4477 Points
Lenovo ThinkPad E550-20DF00CNGE Radeon R7 M265, 5500U, WDC Slim WD10SPCX-22HWST0	4020 Points -10%
HP ProBook 450 G3 HD Graphics 520, 6200U, Seagate ST500LM021-1KJ15	3901 Points -13%
Lenovo ThinkPad L560-20F10026GE HD Graphics 520, 6200U, WDC Slim WD10SPCX-21KHST0	3861 Points -14%

PCMark 8 Home Score Accelerated v2		3337 puan
PCMark 8 Work Score Accelerated v2		4477 puan
Yardım

	Dell Latitude 15-3570 Samsung CM871 MZNLF128HCHP	Lenovo ThinkPad L560-20F10026GE WDC Slim WD10SPCX-21KHST0	HP ProBook 450 G3 Seagate ST500LM021-1KJ15	Lenovo ThinkPad E550-20DF00CNGE WDC Slim WD10SPCX-22HWST0
CrystalDiskMark 3.0		-90%	-90%	-92%
Read Seq	453.2	113.6 -75%	122.8 -73%	101.9 -78%
Read 4k	19.06	0.488 -97%	0.341 -98%	0.315 -98%
Read 4k QD32	93.5	1.367 -99%	0.897 -99%	0.967 -99%
AS SSD
Seq Read	489.1
4K Read	17.25
4K-64 Read	81.8
Score Write	54
Total Average (Program / Settings)		-90% / -90%	-90% / -90%	-92% / -92%

CrystalDiskMark 3.0

AS SSD

Samsung CM871 MZNLF128HCHP

Sequential Read: 453.2 MB/s

Sequential Write: 137.7 MB/s

512K Read: 308.5 MB/s

512K Write: 134.1 MB/s

4K Read: 19.06 MB/s

4K Write: 21.31 MB/s

4K QD32 Read: 93.5 MB/s

4K QD32 Write: 23.3 MB/s

3DMark 11 - 1280x720 Performance GPU
Lenovo ThinkPad E550-20DF00CNGE AMD Radeon R7 M265	2073 Points +63%
Dell Latitude 15-3570 Intel HD Graphics 520	1273 Points
Lenovo ThinkPad L560-20F10026GE Intel HD Graphics 520	1225 Points -4%
HP ProBook 450 G3 Intel HD Graphics 520	1165 Points -8%

3DMark 11 Performance		1363 puan
3DMark Ice Storm Standard Score		46457 puan
3DMark Cloud Gate Standard Score		4919 puan
Yardım

... kıyaslama

	düşük	orta	yüksek
BioShock Infinite (2013)	36.5	20.8	16.8
Metro: Last Light (2013)	17.7	15.3
The Witcher 3 (2015)	11.2	7

Ses yüksekliği

Boşta		31 / 31 / 31 dB
Çalışırken		34.2 / 34.3 dB

	30 dB sessiz 40 dB(A) duyulabilirlik 50 dB(A) gürültülü
min: , med: , max: Audix TM1, Arta (15 cm uzaklık) environment noise: 31 dB(A)

Maksimum yük

Bekleme


31.4 °C	30.9 °C	26.3 °C
31.4 °C	31.7 °C	26.1 °C
30.4 °C	28.7 °C	28.7 °C

Maksimum: 31.7 °C
Ortalama: 29.5 °C


26.6 °C	31.3 °C	31.4 °C
26.5 °C	32.4 °C	32.9 °C
26.6 °C	30.4 °C	32.1 °C

Maksimum: 32.9 °C
Ortalama: 30 °C

Güç kaynağı 34.5 °C | Oda sıcaklığı 22.4 °C | FIRT 550-Pocket

(+) The average temperature for the upper side under maximal load is 31.2 °C / 88 F, compared to the average of 29.5 °C / 85 F for the devices in the class Office.
(+) The maximum temperature on the upper side is 36.1 °C / 97 F, compared to the average of 34.3 °C / 94 F, ranging from 21.2 to 62.5 °C for the class Office.
(-) The bottom heats up to a maximum of 47 °C / 117 F, compared to the average of 36.8 °C / 98 F
(+) In idle usage, the average temperature for the upper side is 29.5 °C / 85 F, compared to the device average of 29.5 °C / 85 F.
(+) The palmrests and touchpad are reaching skin temperature as a maximum (35.8 °C / 96.4 F) and are therefore not hot.
(-) The average temperature of the palmrest area of similar devices was 27.7 °C / 81.9 F (-8.1 °C / -14.5 F).

Anlık tüketim

Kapalı / Bekleme modu	0.45 / 0.8 Watt
Boşta	4.9 / 7.2 / 7.5 Watt
Çalışırken	25.4 / 28 Watt


Key: min: , med: , max: Metrahit Energy

	Dell Latitude 15-3570 HD Graphics 520, 6200U, Samsung CM871 MZNLF128HCHP	Lenovo ThinkPad L560-20F10026GE HD Graphics 520, 6200U, WDC Slim WD10SPCX-21KHST0	HP ProBook 450 G3 HD Graphics 520, 6200U, Seagate ST500LM021-1KJ15	Lenovo ThinkPad E550-20DF00CNGE Radeon R7 M265, 5500U, WDC Slim WD10SPCX-22HWST0
Battery Runtime		-29%	-43%	-43%
Reader / Idle	1024	698 -32%	575 -44%	663 -35%
WiFi v1.3	542	406 -25%	309 -43%	293 -46%
Load	157	109 -31%	90 -43%	82 -48%

Batarya ömrü

Boşta (WLAN kapalı, minimum parlaklık)		17h 04min
WiFi Websurfing		9h 02min
Çalışırken (maksimum parlaklık)		2h 37min

Artılar

+ Seçilebilecek farklı modeller

+ Makul fiyat

+ Kullanışlı kasa

+ PWM yok

+ TPM

+ Yedek diskler mevcut

+ Bakım dostu

+ Makul arayüzler

+ SSD

+ Sessiz ve serin

+ Harika batarya kullanımı

Eksiler

- Tek elle açmak mümkün değil

- Bir yıl üretici garantisi

- Çok düşük ekran çözünürlüğü

- Çok yüksek siyahlık değeri ve zayıf kontrast

- Bakış açısına duyarlı ekran

- Çok zayıf renk üretimi

- Ekran dışarısı için çok karanlık

- Neredeyse hiç kullanışlı olmayan ses sistemi

In review: Dell Latitude 3570. Test model courtesy of Dell Germany

Dell'in Latitude 15-3570 modeli satışda olduğu müddetce ofis çalışanları için en makul fiyat/performans oranını sunduğu söylenebilir. 420 Euroluk bir başlangıç fiyatına iyi kasa, makul arayüler ve uzun kullanım süreleri dahil. Cihazın en büyük eksikliği multimedia bileşenleri olan ses ve ekran yönleri yönünden zayıf olması. Dolayısıyla ofis dışında bir kullanım için uygun bir cihaz değil. Güvenliğe önem veren kullanıcılar için TPM ve opsiyonel parmak izi okuyucu mevcut.

Yazının orjinali için tıklayın.

Dell Latitude 15-3570 - 07/01/2016 v5.1 ^(old)
Sven Kloevekorn

İşcilik

73 / 98 → 75%

Klavye

82%

Mouse

84%

Bağlanılabilirlik

43 / 80 → 54%

Ağırlık

63 / 20-67 → 91%
