MagyarKısa inceleme: HP EliteBook 745 G3 (FHD) Notebook
HP EliteBook 745 G3 (EliteBook 700 Seri)
İşlemci
AMD Pro A12-8800B 4 x 2.1 - 3.4 GHz, Carrizo
Grafik kartı
AMD Radeon R7 (Carrizo), Çekirdek: 800 MHz, 15.201.1001.1005
Bellek
8 GB
, DDR3-1600
Görüntü
14.00 inç 16:9, 1920 x 1080 pixel, No, CMN14C0, TN LED, parlak: hayır
Anakart
AMD KernCZ
Harddisk
SanDisk X300s SD7TN3Q-256G-1006, 256 GB
Ağırlık
1.55 kg, Güç kaynağı: 292 g
Bağlantılar
Note: The manufacturer may use components from different suppliers including display panels, drives or memory sticks with similar specifications.
| |||||||||||||||||||||||||
CMN14C0 tested with X-Rite i1Basic Pro 2
Maksimum: 366.2 cd/m² (Nits) Ortalama: 343.1 cd/m²Aydınlatma: 89 %
Batarya modunda parlaklık: 366.2 cd/m²
Kontrast: 513:1 (Siyah: 0.714 cd/m²)
ΔE Color 9.15 | 0.5-29.43 Ø4.92
ΔE Greyscale 9.57 | 0.5-98 Ø5.2
77.28% sRGB (Argyll 1.6.3 3D)
49.03% AdobeRGB 1998 (Argyll 1.6.3 3D)
52.6% AdobeRGB 1998 (Argyll 2.2.0 3D)
76.7% sRGB (Argyll 2.2.0 3D)
50.9% Display P3 (Argyll 2.2.0 3D)
Gamma: 2.19
| HP EliteBook 745 G3 14", 1920x1080 | HP EliteBook 745 G3 14", 2560x1440 | Dell Latitude E7450 14", 1920x1080 | Lenovo ThinkPad T450s-20BWS1UT00 14", 1920x1080 | Toshiba Portege Z30t-B1320W10 13.3", 1920x1080 | |
|---|---|---|---|---|---|
| Display | 39% | 27% | 17% | 30% | |
| Display P3 Coverage | 50.9 | 75.7 49% | 66.6 31% | 64.8 27% | 67.1 32% |
| sRGB Coverage | 76.7 | 95.8 25% | 92.4 20% | 83.8 9% | 96.8 26% |
| AdobeRGB 1998 Coverage | 52.6 | 74.5 42% | 67.7 29% | 61.2 16% | 68.9 31% |
| Response Times | 19% | -18% | |||
| Response Time Grey 50% / Grey 80% * | 54 ? | 46.8 ? 13% | 59.2 ? -10% | ||
| Response Time Black / White * | 33 ? | 25.2 ? 24% | 50.4 ? -53% | ||
| PWM Frequency | 200 ? | 215.5 8% | |||
| Screen | 27% | 27% | 31% | 35% | |
| Brightness middle | 366.2 | 319 -13% | 280 -24% | 288 -21% | 296.1 -19% |
| Brightness | 343 | 301 -12% | 257 -25% | 281 -18% | 284 -17% |
| Brightness Distribution | 89 | 74 -17% | 75 -16% | 94 6% | 90 1% |
| Black Level * | 0.714 | 0.29 59% | 0.3 58% | 0.286 60% | 0.308 57% |
| Contrast | 513 | 1100 114% | 933 82% | 1007 96% | 961 87% |
| Colorchecker dE 2000 * | 9.15 | 7.23 21% | 3.45 62% | 4.35 52% | 3 67% |
| Colorchecker dE 2000 max. * | 15.11 | ||||
| Greyscale dE 2000 * | 9.57 | 6 37% | 3.35 65% | 3.7 61% | 1.61 83% |
| Gamma | 2.19 100% | 2.14 103% | 2.37 93% | 2.68 82% | 2.18 101% |
| CCT | 11114 58% | 6904 94% | 6940 94% | 6076 107% | 6716 97% |
| Color Space (Percent of AdobeRGB 1998) | 49.03 | 65.8 34% | 60 22% | 54.7 12% | 62.37 27% |
| Color Space (Percent of sRGB) | 77.28 | 95.3 23% | 92 19% | 96.57 25% | |
| Total Average (Program / Settings) | 28% /
29% | 27% /
27% | 24% /
27% | 16% /
23% |
* ... smaller is better
Display Response Times
ℹ
Display response times show how fast the screen is able to change from one color to the next. Slow response times can lead to afterimages and can cause moving objects to appear blurry (ghosting). Gamers of fast-paced 3D titles should pay special attention to fast response times.| ↔ Response Time Black to White | ||
|---|---|---|
| 33 ms ... rise ↗ and fall ↘ combined | ↗ 15 ms rise |  |
| ↘ 18 ms fall | ||
| The screen shows slow response rates in our tests and will be unsatisfactory for gamers. In comparison, all tested devices range from 0.1 (minimum) to 240 (maximum) ms. » 88 % of all devices are better. This means that the measured response time is worse than the average of all tested devices (21 ms). | ||
| ↔ Response Time 50% Grey to 80% Grey | ||
| 54 ms ... rise ↗ and fall ↘ combined | ↗ 29 ms rise |  |
| ↘ 25 ms fall | ||
| The screen shows slow response rates in our tests and will be unsatisfactory for gamers. In comparison, all tested devices range from 0.165 (minimum) to 636 (maximum) ms. » 90 % of all devices are better. This means that the measured response time is worse than the average of all tested devices (32.9 ms). | ||
Screen Flickering / PWM (Pulse-Width Modulation)
ℹ
To dim the screen, some notebooks will simply cycle the backlight on and off in rapid succession - a method called Pulse Width Modulation (PWM) . This cycling frequency should ideally be undetectable to the human eye. If said frequency is too low, users with sensitive eyes may experience strain or headaches or even notice the flickering altogether.| Screen flickering / PWM detected | 200 Hz | ≤ 90 % brightness setting |  |
| ≤ 343 cd/m² brightness | |||
The display backlight flickers at 200 Hz (worst case, e.g., utilizing PWM) Flickering detected at a brightness setting of 90 % (343 cd/m²) and below. There should be no flickering or PWM above this brightness setting. The frequency of 200 Hz is relatively low, so sensitive users will likely notice flickering and experience eyestrain at the stated brightness setting and below. Flickering occurs even at high brightness setting and may have an effect on the user during everyday use. In comparison: 53 % of all tested devices do not use PWM to dim the display. If PWM was detected, an average of 8747 (minimum: 5 - maximum: 343500) Hz was measured. | |||
| Cinebench R10 | |
| Rendering Single CPUs 64Bit (sort by value) | |
| HP EliteBook 745 G3 | |
| HP EliteBook 745 G3 | |
| Dell Latitude E7450 | |
| Lenovo ThinkPad T450s-20BWS1UT00 | |
| Toshiba Portege Z30t-B1320W10 | |
| Rendering Multiple CPUs 64Bit (sort by value) | |
| HP EliteBook 745 G3 | |
| HP EliteBook 745 G3 | |
| Dell Latitude E7450 | |
| Lenovo ThinkPad T450s-20BWS1UT00 | |
| Toshiba Portege Z30t-B1320W10 | |
| PCMark 7 - Score (sort by value) | |
| HP EliteBook 745 G3 | |
| HP EliteBook 745 G3 | |
| Dell Latitude E7450 | |
| Lenovo ThinkPad T450s-20BWS1UT00 | |
| Toshiba Portege Z30t-B1320W10 | |
| PCMark 7 Score | 4729 puan | |
| PCMark 8 Home Score Accelerated v2 | 2978 puan | |
| PCMark 8 Creative Score Accelerated v2 | 3717 puan | |
| PCMark 8 Work Score Accelerated v2 | 3824 puan | |
Yardım | ||
SanDisk X300s SD7TN3Q-256G-1006
Maksimum transfer hızı:
354.9 MB/s
Minimum transfer hızı:
385.4 MB/s
Ortlama transfer hızı:
373.1 MB/s
Erişim hızı:
0.2 ms
Yakma hızı:
70.9 MB/s
İşlemci kullanımı:
5.5 %
| 3DMark 11 - 1280x720 Performance (sort by value) | |
| HP EliteBook 745 G3 | |
| HP EliteBook 745 G3 | |
| Dell Latitude E7450 | |
| Lenovo ThinkPad T450s-20BWS1UT00 | |
| Toshiba Portege Z30t-B1320W10 | |
| 3DMark | |
| 1920x1080 Fire Strike Score (sort by value) | |
| HP EliteBook 745 G3 | |
| HP EliteBook 745 G3 | |
| Dell Latitude E7450 | |
| Lenovo ThinkPad T450s-20BWS1UT00 | |
| Toshiba Portege Z30t-B1320W10 | |
| 1280x720 Cloud Gate Standard Score (sort by value) | |
| HP EliteBook 745 G3 | |
| HP EliteBook 745 G3 | |
| Dell Latitude E7450 | |
| Lenovo ThinkPad T450s-20BWS1UT00 | |
| Toshiba Portege Z30t-B1320W10 | |
| 1280x720 Ice Storm Standard Score (sort by value) | |
| HP EliteBook 745 G3 | |
| HP EliteBook 745 G3 | |
| Dell Latitude E7450 | |
| Lenovo ThinkPad T450s-20BWS1UT00 | |
| Toshiba Portege Z30t-B1320W10 | |
| 3DMark 06 Standard Score | 7857 puan | |
| 3DMark 11 Performance | 2020 puan | |
| 3DMark Ice Storm Standard Score | 45140 puan | |
| 3DMark Cloud Gate Standard Score | 5005 puan | |
| 3DMark Fire Strike Score | 1170 puan | |
| 3DMark Fire Strike Extreme Score | 540 puan | |
Yardım | ||
| HP EliteBook 745 G3 Radeon R7 (Carrizo), Pro A12-8800B, SanDisk X300s SD7TN3Q-256G-1006 | HP EliteBook 745 G3 Radeon R7 (Carrizo), Pro A12-8800B, Samsung SSD PM851 256 GB MZNTE256HMHP | Dell Latitude E7450 HD Graphics 5500, 5300U, Samsung SSD PM851 mSATA 128 GB | Lenovo ThinkPad T450s-20BWS1UT00 GeForce 940M, 5200U, Samsung SSD PM871 MZ7LN256HCHP | Toshiba Portege Z30t-B1320W10 HD Graphics 5500, 5600U, Toshiba THNSNJ256GMCU | |
|---|---|---|---|---|---|
| Noise | -8% | -9% | -4% | -11% | |
| Idle Minimum * | 28.5 | 29 -2% | 29.1 -2% | 29.1 -2% | 30.2 -6% |
| Idle Average * | 28.6 | 29 -1% | 29.1 -2% | 29.1 -2% | 30.3 -6% |
| Idle Maximum * | 28.6 | 31.1 -9% | 30 -5% | 29.1 -2% | 32.2 -13% |
| Load Average * | 30.5 | 35.6 -17% | 36.4 -19% | 33.1 -9% | 35.6 -17% |
| Load Maximum * | 32.6 | 35.6 -9% | 37.8 -16% | 34.3 -5% | 37.6 -15% |
* ... smaller is better
Ses yüksekliği
| Boşta |
| 28.5 / 28.6 / 28.6 dB |
| Çalışırken |
| 30.5 / 32.6 dB |
 | ||
30 dB sessiz 40 dB(A) duyulabilirlik 50 dB(A) gürültülü |
||
min:  , med:  , max:  BK Precision 732A (15 cm uzaklık) | ||
(+) The average temperature for the upper side under maximal load is 29.6 °C / 85 F, compared to the average of 29.5 °C / 85 F for the devices in the class Office.
(+) The maximum temperature on the upper side is 36.8 °C / 98 F, compared to the average of 34.3 °C / 94 F, ranging from 21.2 to 62.5 °C for the class Office.
(±) The bottom heats up to a maximum of 43.8 °C / 111 F, compared to the average of 36.8 °C / 98 F
(+) In idle usage, the average temperature for the upper side is 26 °C / 79 F, compared to the device average of 29.5 °C / 85 F.
(+) The palmrests and touchpad are cooler than skin temperature with a maximum of 26 °C / 78.8 F and are therefore cool to the touch.
(±) The average temperature of the palmrest area of similar devices was 27.7 °C / 81.9 F (+1.7 °C / 3.1 F).
(+) The maximum temperature on the upper side is 36.8 °C / 98 F, compared to the average of 34.3 °C / 94 F, ranging from 21.2 to 62.5 °C for the class Office.
(±) The bottom heats up to a maximum of 43.8 °C / 111 F, compared to the average of 36.8 °C / 98 F
(+) In idle usage, the average temperature for the upper side is 26 °C / 79 F, compared to the device average of 29.5 °C / 85 F.
(+) The palmrests and touchpad are cooler than skin temperature with a maximum of 26 °C / 78.8 F and are therefore cool to the touch.
(±) The average temperature of the palmrest area of similar devices was 27.7 °C / 81.9 F (+1.7 °C / 3.1 F).
Artılar
+ Sağlam, metal kasa
+ Harika klavye
+ Rahat ve tutarlı touchpad
+ Hızlı SSD
+ Çok iyi genel sistem performansı
+ Parlak, mat 1080p ekran
+ Rekabete uygun fiyatlama
+ Temiz, sesli hoparlörler
+ Boş 2.5 inç M.2 SSD konfigrasyonlu disk alanı
Eksiler
- Bakım zor
- Renk üretimi zayıf ve ortalama kontrast
- Sadece en yüksek parlaklıkta PWM
- İşlemci ve grafik kartı performansı sıcaklık üretimi yüzüncen kısıtlı
- Rahatsız edici işlemci sesi
- Sınıf için ortalamanın altında batarya ömrü
HP'nin Elitebook 745 G3 modelinde aydınlığı ve karanlığı çok ufak bir çizgi ayırıyor. Açıklamak gerekirse, cihazın güçlü yanları yüksek kalite kasası, harika arayüzleri ve mükemmel ekranı. Uygulama performansı da oldukça iyi. SSD sayesinde cihaz oldukça hızlı tepki veriyor ve açılış ile yükleme sürelerinde oldukça hızlı. Carrizo işlemci gündelik kullanım için yeterli performansı sunuyor. Ancak A12-8800B işlemcinin mevcut Core i3 işlemci seviyelerine ulaşamamasını da eleştirmek gerekir.
HP'nin bakım kapağı ve USB portları ile ilgili tercihi konusunda biraz konuşmak gerekir. Ek USB Type C port geleceğe yönelik olsa da, port sayısının azaltılması yerinde bir karar değil. Kısa batarya ömrü, kötü webcam bu fiyat aralığındaki bir cihaz üzerinde iyi durmuyor.
Ne kadar ekmek o kadar köfte sözü bir kere daha doğru çıkıyor. Elitebook 800 serisine kıyasla düşük kalan fiyatın sebeplerini anlamak mümkün. Ama bu hiçbir şekilde 743 G3 modelini kötü bir cihaz yapmıyor.
Yazının orjinali için tıklayın.
HP EliteBook 745 G3
-
01/28/2016 v4.1 (old)
Steve Schardein
