Kısa inceleme: HP EliteBook Folio 1020 G1 Ultrabook
HP EliteBook Folio 1020 G1 (Elitebook Folio 1020 Seri)
İşlemci
Intel Core M-5Y51 2 x 1.1 - 2.6 GHz, Broadwell
Grafik kartı
Intel HD Graphics 5300, Çekirdek: 900 MHz, Bellek: 800 MHz, 10.18.10.4013
Bellek
8 GB
, dual-channel 1600 MHz LPDDR3
Görüntü
12.50 inç 16:9, 2560 x 1440 pixel, capacitive touchscreen, Sharp SHP142F, IPS, parlak: evet
Anakart
Intel Broadwell-Y PCH-LP (Premium)
Harddisk
Samsung PM851 Series MZMTE256HMHP, 256 GB
, 196 GB Boş
Ağırlık
1.245 kg, Güç kaynağı: 317 g
Fiyat
2250 Euro
Bağlantılar
Note: The manufacturer may use components from different suppliers including display panels, drives or memory sticks with similar specifications.
| HP EliteBook Folio 1020 G1 HD Graphics 5300, 5Y51, Samsung PM851 Series MZMTE256HMHP | Lenovo ThinkPad X250-20CLS06D00 HD Graphics 5500, 5600U, Intel SSD Pro 2500 Series SSDSC2BF360A5L | Dell Latitude 12 E7250 HD Graphics 5500, 5300U, Samsung PM851 Series MZMTE256HMHP | HP EliteBook 820 G1 HD Graphics 4400, 4600U, Intel SSD Pro 1500 Series SSDSC2BF180A4H | |
|---|---|---|---|---|
| Display | -33% | -33% | -40% | |
| Display P3 Coverage | 67.3 | 44.14 -34% | 44.48 -34% | 39.89 -41% |
| sRGB Coverage | 96.2 | 65.8 -32% | 66.2 -31% | 59 -39% |
| AdobeRGB 1998 Coverage | 68.9 | 45.71 -34% | 45.96 -33% | 40.98 -41% |
| Screen | -8% | -27% | -98% | |
| Brightness middle | 306 | 397 30% | 360 18% | 229 -25% |
| Brightness | 297 | 357 20% | 330 11% | 211 -29% |
| Brightness Distribution | 80 | 81 1% | 81 1% | 86 8% |
| Black Level * | 0.3141 | 0.44 -40% | 0.53 -69% | 0.63 -101% |
| Contrast | 974 | 902 -7% | 679 -30% | 363 -63% |
| Colorchecker dE 2000 * | 3.01 | 4.2 -40% | 5.58 -85% | 10.75 -257% |
| Greyscale dE 2000 * | 3.13 | 3.1 1% | 3.98 -27% | 11.72 -274% |
| Gamma | 2.33 94% | 2.6 85% | 2.21 100% | 2.62 84% |
| CCT | 6484 100% | 6246 104% | 6192 105% | 15283 43% |
| Color Space (Percent of AdobeRGB 1998) | 62 | 42 -32% | 42.2 -32% | 37 -40% |
| Color Space (Percent of sRGB) | 65.5 | |||
| Total Average (Program / Settings) | -21% /
-15% | -30% /
-28% | -69% /
-82% |
* ... smaller is better
| |||||||||||||||||||||||||
Sharp SHP142F tested with X-Rite i1Pro 2
Maksimum: 331 cd/m² (Nits) Ortalama: 297.2 cd/m²Aydınlatma: 80 %
Batarya modunda parlaklık: 307 cd/m²
Kontrast: 974:1 (Siyah: 0.3141 cd/m²)
ΔE Color 3.01 | 0.5-29.43 Ø4.91
ΔE Greyscale 3.13 | 0.5-98 Ø5.2
62% AdobeRGB 1998 (Argyll 1.6.3 3D)
68.9% AdobeRGB 1998 (Argyll 2.2.0 3D)
96.2% sRGB (Argyll 2.2.0 3D)
67.3% Display P3 (Argyll 2.2.0 3D)
Gamma: 2.33
| HP EliteBook Folio 1020 G1 HD Graphics 5300, 5Y51, Samsung PM851 Series MZMTE256HMHP | Dell Latitude 12 E7250 HD Graphics 5500, 5300U, Samsung PM851 Series MZMTE256HMHP | Lenovo ThinkPad X250-20CLS06D00 HD Graphics 5500, 5600U, Intel SSD Pro 2500 Series SSDSC2BF360A5L | HP EliteBook 820 G1 HD Graphics 4400, 4600U, Intel SSD Pro 1500 Series SSDSC2BF180A4H | |
|---|---|---|---|---|
| PCMark 8 | 21% | 37% | 49% | |
| Home Score Accelerated v2 | 2191 | 2772 27% | 3148 44% | 3624 65% |
| Creative Score Accelerated v2 | 2644 | 3052 15% | 3458 31% | 3045 15% |
| Work Score Accelerated v2 | 3217 | 4345 35% | 5363 67% | |
| PCMark 7 | ||||
| Score | 4045 | 4662 15% | 4609 14% | 5196 28% |
| Total Average (Program / Settings) | 18% /
19% | 26% /
31% | 39% /
44% |
| PCMark 7 Score | 4045 puan | |
| PCMark 8 Home Score Accelerated v2 | 2191 puan | |
| PCMark 8 Creative Score Accelerated v2 | 2644 puan | |
| PCMark 8 Work Score Accelerated v2 | 3217 puan | |
Yardım | ||
| HP EliteBook Folio 1020 G1 HD Graphics 5300, 5Y51, Samsung PM851 Series MZMTE256HMHP | Dell Latitude 12 E7250 HD Graphics 5500, 5300U, Samsung PM851 Series MZMTE256HMHP | Lenovo ThinkPad X250-20CLS06D00 HD Graphics 5500, 5600U, Intel SSD Pro 2500 Series SSDSC2BF360A5L | HP EliteBook 820 G1 HD Graphics 4400, 4600U, Intel SSD Pro 1500 Series SSDSC2BF180A4H | |
|---|---|---|---|---|
| CrystalDiskMark 3.0 | -10% | -33% | -5% | |
| Read Seq | 518 | 509 -2% | 419.8 -19% | 428.5 -17% |
| Write Seq | 239.5 | 244 2% | 228.6 -5% | 263.8 10% |
| Read 512 | 415.6 | 428 3% | 355.2 -15% | 352.5 -15% |
| Write 512 | 237.9 | 244 3% | 203.3 -15% | 261.7 10% |
| Read 4k | 28.17 | 29 3% | 27.86 -1% | 28.44 1% |
| Write 4k | 91.2 | 61 -33% | 15.3 -83% | 124 36% |
| Read 4k QD32 | 327.3 | 214 -35% | 163.9 -50% | 156.5 -52% |
| Write 4k QD32 | 234.8 | 180 -23% | 60.2 -74% | 198.2 -16% |
Samsung PM851 Series MZMTE256HMHP
Sequential Read:
518 MB/s
Sequential Write:
239.5 MB/s
512K Read:
415.6 MB/s
512K Write:
237.9 MB/s
4K Read:
28.17 MB/s
4K Write:
91.2 MB/s
4K QD32 Read:
327.3 MB/s
4K QD32 Write:
234.8 MB/s
| 3DMark 11 - 1280x720 Performance (sort by value) | |
| HP EliteBook Folio 1020 G1 | |
| Dell Latitude 12 E7250 | |
| Lenovo ThinkPad X250-20CLS06D00 | |
| HP EliteBook 820 G1 | |
| 3DMark 11 Performance | 615 puan | |
| 3DMark Ice Storm Standard Score | 25301 puan | |
| 3DMark Cloud Gate Standard Score | 2814 puan | |
Yardım | ||
| Middle-earth: Shadow of Mordor - 1280x720 Lowest Preset (sort by value) | |
| HP EliteBook Folio 1020 G1 | |
| Dell Latitude 12 E7250 | |
| düşük | orta | yüksek | ultra | |
|---|---|---|---|---|
| Fifa 15 (2014) | 19.1 | 16.2 | ||
| Middle-earth: Shadow of Mordor (2014) | 12.31 | 7.92 | 4.33 | |
| Alien: Isolation (2014) | 17.75 | 11.57 | 6.63 | 4.63 |
Ses yüksekliği
| Boşta |
| / / dB |
| Çalışırken |
| / dB |
 | ||
30 dB sessiz 40 dB(A) duyulabilirlik 50 dB(A) gürültülü |
||
min:  , med:  , max:  Voltcraft sl-451 (15 cm uzaklık) | ||
(±) The average temperature for the upper side under maximal load is 32.1 °C / 90 F, compared to the average of 30.8 °C / 87 F for the devices in the class Subnotebook.
(+) The maximum temperature on the upper side is 37 °C / 99 F, compared to the average of 35.9 °C / 97 F, ranging from 21.4 to 59 °C for the class Subnotebook.
(+) The bottom heats up to a maximum of 39.6 °C / 103 F, compared to the average of 39.4 °C / 103 F
(+) In idle usage, the average temperature for the upper side is 26.4 °C / 80 F, compared to the device average of 30.8 °C / 87 F.
(+) The palmrests and touchpad are reaching skin temperature as a maximum (32.4 °C / 90.3 F) and are therefore not hot.
(-) The average temperature of the palmrest area of similar devices was 28.3 °C / 82.9 F (-4.1 °C / -7.4 F).
(+) The maximum temperature on the upper side is 37 °C / 99 F, compared to the average of 35.9 °C / 97 F, ranging from 21.4 to 59 °C for the class Subnotebook.
(+) The bottom heats up to a maximum of 39.6 °C / 103 F, compared to the average of 39.4 °C / 103 F
(+) In idle usage, the average temperature for the upper side is 26.4 °C / 80 F, compared to the device average of 30.8 °C / 87 F.
(+) The palmrests and touchpad are reaching skin temperature as a maximum (32.4 °C / 90.3 F) and are therefore not hot.
(-) The average temperature of the palmrest area of similar devices was 28.3 °C / 82.9 F (-4.1 °C / -7.4 F).
| HP EliteBook Folio 1020 G1 HD Graphics 5300, 5Y51, Samsung PM851 Series MZMTE256HMHP | Dell Latitude 12 E7250 HD Graphics 5500, 5300U, Samsung PM851 Series MZMTE256HMHP | Lenovo ThinkPad X250-20CLS06D00 HD Graphics 5500, 5600U, Intel SSD Pro 2500 Series SSDSC2BF360A5L | HP EliteBook 820 G1 HD Graphics 4400, 4600U, Intel SSD Pro 1500 Series SSDSC2BF180A4H | |
|---|---|---|---|---|
| Power Consumption | -61% | -45% | -31% | |
| Idle Minimum * | 3.4 | 4.1 -21% | 2.7 21% | 3.2 6% |
| Idle Average * | 6.7 | 8.3 -24% | 7 -4% | 5.2 22% |
| Idle Maximum * | 7.5 | 9.4 -25% | 8 -7% | 7.5 -0% |
| Load Average * | 14.6 | 31.6 -116% | 28.6 -96% | 34.3 -135% |
| Load Maximum * | 18.4 | 40.4 -120% | 44.3 -141% | 26.8 -46% |
* ... smaller is better
Anlık tüketim
| Kapalı / Bekleme modu | 0 / 0.1 Watt |
| Boşta | 3.4 / 6.7 / 7.5 Watt |
| Çalışırken |
14.6 / 18.4 Watt |

| |
Key:
min: ,
med: ,
max: Extech Power Analyzer 380803 | |
| HP EliteBook Folio 1020 G1 HD Graphics 5300, 5Y51, Samsung PM851 Series MZMTE256HMHP | Dell Latitude 12 E7250 HD Graphics 5500, 5300U, Samsung PM851 Series MZMTE256HMHP | Lenovo ThinkPad X250-20CLS06D00 HD Graphics 5500, 5600U, Intel SSD Pro 2500 Series SSDSC2BF360A5L | HP EliteBook 820 G1 HD Graphics 4400, 4600U, Intel SSD Pro 1500 Series SSDSC2BF180A4H | |
|---|---|---|---|---|
| Battery Runtime | ||||
| WiFi Websurfing | 412 | 298 -28% | ||
| Battery Runtime | -5% | -13% | -1% | |
| Reader / Idle | 660 | 845 28% | 779 18% | 813 23% |
| Load | 164 | 103 -37% | 92 -44% | 124 -24% |
| Total Average (Program / Settings) | -5% /
-5% | -21% /
-18% | -1% /
-1% |
Artılar
+ Kasanın kalitesi
+ Klavye
+ Yüksek kalite QHD IPS ekran
+ Isı üretimi
+ Ses üretimi yok
+ Akıcı çalışması
Eksiler
- Rekabete kıyasla performansı
- Fiyat/Performans
- Touchpad
- Hoparlörler
HP'nin EliteBook Folio 1020 modeli kendisini hareketli ofis olarak pozisyonlamayı gerçekten başarıyor. Bu noktada özellikle yapım kalitesinde eleştirebileceğimiz bir şey yok. Aluminyum kasa tatmin ediyor, ekran yine yüksek bir kaliteye sahip. Bağlantı noktasında biraz eksiklik hissetmiş olsak da, HP ücretsiz bir adaptör ile bu sorunu çözüyor. Malesef batarya artık çıkarılamıyor. Cihaz tamamen fansız tasarıma geçmiş. Ekran sadece dokunmatik değil, aynı zamanda QHD. Malesef mat ekran versiyonu yok. İnce 12.5 inçlik cihazda fan olmadığı için performans yönünden ödün vermek gerekmiş. Seçilen Broadwell işlemci rakiplerle pek mücadele edemese de, sunduğu performans gündelik işler için yeterli.
Genel olarak bakıldığında HP'nin Elitebook Folio 1020 modeli küçük, iyi işlenmiş, yüksek kaliteli bir çalışma arkadaşı. Elbette 2250 Euroluk fiyata değip değmeyeceğine alıcı karar verecek.
Yazının orjinali için tıklayın.
HP EliteBook Folio 1020 G1
