MagyarKısa inceleme: HP ZBook 15u G3 çalışma istasyonu
HP ZBook 15u G3 (ZBook 15u G4 Seri)
İşlemci
Intel Core i7-6600U 2 x 2.6 - 3.4 GHz @ 2.6 GHz, Skylake
Grafik kartı
AMD FirePro W4190M - 2048 MB VRAM, Çekirdek: 900 MHz, Bellek: 4000 MHz, GDDR5, 15.201.1701.1005
Bellek
16 GB
, DDR4-2133
Görüntü
15.60 inç 16:9, 1920 x 1080 pixel, 10-point multitouch , CMN15C3, TN LED, parlak: evet
Anakart
Intel Sunrise Point-LP
Harddisk
Samsung SM951 MZVPV256HDGL m.2 PCI-e, 256 GB
Ağırlık
2.166 kg, Güç kaynağı: 318 g
Bağlantılar
Note: The manufacturer may use components from different suppliers including display panels, drives or memory sticks with similar specifications.
| |||||||||||||||||||||||||
CMN15C3 tested with X-Rite i1Basic Pro 2
Maksimum: 297.8 cd/m² (Nits) Ortalama: 283.8 cd/m²Aydınlatma: 89 %
Batarya modunda parlaklık: 297.8 cd/m²
Kontrast: 351:1 (Siyah: 0.849 cd/m²)
ΔE Color 8.68 | 0.5-29.43 Ø4.93
ΔE Greyscale 9.3 | 0.5-98 Ø5.2
80.42% sRGB (Argyll 1.6.3 3D)
50.99% AdobeRGB 1998 (Argyll 1.6.3 3D)
54.9% AdobeRGB 1998 (Argyll 2.2.0 3D)
80.1% sRGB (Argyll 2.2.0 3D)
53.2% Display P3 (Argyll 2.2.0 3D)
Gamma: 2.27
| HP ZBook 15u G3 15.6", 1920x1080 | Lenovo ThinkPad W550s 20E2-000PGE 15.5", 2880x1620 | Dell Precision 5510 15.6", 3840x2160 | HP ZBook 15 G2 15.6", 1920x1080 | |
|---|---|---|---|---|
| Display | 13% | 57% | 26% | |
| Display P3 Coverage | 53.2 | 62.3 17% | 88.4 66% | 68.5 29% |
| sRGB Coverage | 80.1 | 86.5 8% | 100 25% | 97.3 21% |
| AdobeRGB 1998 Coverage | 54.9 | 62.6 14% | 99.5 81% | 70.7 29% |
| Response Times | -12% | |||
| Response Time Grey 50% / Grey 80% * | 45.6 ? | 56.4 ? -24% | ||
| Response Time Black / White * | 34.4 ? | 34 ? 1% | ||
| PWM Frequency | 198.4 ? | |||
| Screen | 33% | 56% | 31% | |
| Brightness middle | 297.8 | 360 21% | 391 31% | 309 4% |
| Brightness | 284 | 323 14% | 361 27% | 289 2% |
| Brightness Distribution | 89 | 81 -9% | 87 -2% | 84 -6% |
| Black Level * | 0.849 | 0.54 36% | 0.4 53% | 0.47 45% |
| Contrast | 351 | 667 90% | 978 179% | 657 87% |
| Colorchecker dE 2000 * | 8.68 | 3.45 60% | 4.85 44% | 3.82 56% |
| Colorchecker dE 2000 max. * | 14.98 | |||
| Greyscale dE 2000 * | 9.3 | 2.98 68% | 4.01 57% | 5.94 36% |
| Gamma | 2.27 97% | 2.06 107% | 2.18 101% | 2.16 102% |
| CCT | 10585 61% | 6338 103% | 7340 89% | 6996 93% |
| Color Space (Percent of AdobeRGB 1998) | 50.99 | 56 10% | 96 88% | 63.8 25% |
| Color Space (Percent of sRGB) | 80.42 | 86.3 7% | 100 24% | |
| Total Average (Program / Settings) | 23% /
28% | 34% /
46% | 29% /
30% |
* ... smaller is better
Display Response Times
ℹ
Display response times show how fast the screen is able to change from one color to the next. Slow response times can lead to afterimages and can cause moving objects to appear blurry (ghosting). Gamers of fast-paced 3D titles should pay special attention to fast response times.| ↔ Response Time Black to White | ||
|---|---|---|
| 34.4 ms ... rise ↗ and fall ↘ combined | ↗ 16.4 ms rise |  |
| ↘ 18 ms fall | ||
| The screen shows slow response rates in our tests and will be unsatisfactory for gamers. In comparison, all tested devices range from 0.1 (minimum) to 240 (maximum) ms. » 91 % of all devices are better. This means that the measured response time is worse than the average of all tested devices (21 ms). | ||
| ↔ Response Time 50% Grey to 80% Grey | ||
| 45.6 ms ... rise ↗ and fall ↘ combined | ↗ 25.6 ms rise |  |
| ↘ 20 ms fall | ||
| The screen shows slow response rates in our tests and will be unsatisfactory for gamers. In comparison, all tested devices range from 0.165 (minimum) to 636 (maximum) ms. » 76 % of all devices are better. This means that the measured response time is worse than the average of all tested devices (32.9 ms). | ||
Screen Flickering / PWM (Pulse-Width Modulation)
ℹ
To dim the screen, some notebooks will simply cycle the backlight on and off in rapid succession - a method called Pulse Width Modulation (PWM) . This cycling frequency should ideally be undetectable to the human eye. If said frequency is too low, users with sensitive eyes may experience strain or headaches or even notice the flickering altogether.| Screen flickering / PWM detected | 198.4 Hz | ≤ 90 % brightness setting |  |
The display backlight flickers at 198.4 Hz (worst case, e.g., utilizing PWM) Flickering detected at a brightness setting of 90 % and below. There should be no flickering or PWM above this brightness setting. The frequency of 198.4 Hz is relatively low, so sensitive users will likely notice flickering and experience eyestrain at the stated brightness setting and below. In comparison: 53 % of all tested devices do not use PWM to dim the display. If PWM was detected, an average of 8774 (minimum: 5 - maximum: 343500) Hz was measured. | |||
| Cinebench R10 | |
| Rendering Single CPUs 64Bit (sort by value) | |
| Dell Precision 5510 | |
| Lenovo ThinkPad W550s 20E2-000PGE | |
| HP ZBook 15 G2 | |
| Rendering Multiple CPUs 64Bit (sort by value) | |
| Dell Precision 5510 | |
| Lenovo ThinkPad W550s 20E2-000PGE | |
| HP ZBook 15 G2 | |
| Cinebench R11.5 | |
| CPU Single 64Bit (sort by value) | |
| HP ZBook 15u G3 | |
| Dell Precision 5510 | |
| Lenovo ThinkPad W550s 20E2-000PGE | |
| HP ZBook 15 G2 | |
| CPU Multi 64Bit (sort by value) | |
| HP ZBook 15u G3 | |
| Dell Precision 5510 | |
| Lenovo ThinkPad W550s 20E2-000PGE | |
| HP ZBook 15 G2 | |
| Cinebench R15 | |
| CPU Single 64Bit (sort by value) | |
| HP ZBook 15u G3 | |
| Dell Precision 5510 | |
| Lenovo ThinkPad W550s 20E2-000PGE | |
| HP ZBook 15 G2 | |
| CPU Multi 64Bit (sort by value) | |
| HP ZBook 15u G3 | |
| Dell Precision 5510 | |
| Lenovo ThinkPad W550s 20E2-000PGE | |
| HP ZBook 15 G2 | |
| PCMark 7 - Score (sort by value) | |
| HP ZBook 15u G3 | |
| Dell Precision 5510 | |
| Lenovo ThinkPad W550s 20E2-000PGE | |
| HP ZBook 15 G2 | |
| PCMark 8 | |
| Home Score Accelerated v2 (sort by value) | |
| HP ZBook 15u G3 | |
| Dell Precision 5510 | |
| Lenovo ThinkPad W550s 20E2-000PGE | |
| HP ZBook 15 G2 | |
| Work Score Accelerated v2 (sort by value) | |
| HP ZBook 15u G3 | |
| Dell Precision 5510 | |
| Lenovo ThinkPad W550s 20E2-000PGE | |
| HP ZBook 15 G2 | |
| Creative Score Accelerated v2 (sort by value) | |
| HP ZBook 15u G3 | |
| Dell Precision 5510 | |
| Lenovo ThinkPad W550s 20E2-000PGE | |
| HP ZBook 15 G2 | |
| PCMark 7 Score | 5493 puan | |
| PCMark 8 Home Score Accelerated v2 | 3974 puan | |
| PCMark 8 Creative Score Accelerated v2 | 4453 puan | |
| PCMark 8 Work Score Accelerated v2 | 4900 puan | |
Yardım | ||
Samsung SM951 MZVPV256HDGL m.2 PCI-e
Maksimum transfer hızı:
990 MB/s
Minimum transfer hızı:
1140 MB/s
Ortlama transfer hızı:
1127 MB/s
Erişim hızı:
0.1 ms
Yakma hızı:
231.5 MB/s
İşlemci kullanımı:
5.7 %
| 3DMark 06 Standard Score | 12929 puan | |
| 3DMark 11 Performance | 2173 puan | |
| 3DMark Ice Storm Standard Score | 37532 puan | |
| 3DMark Cloud Gate Standard Score | 6567 puan | |
| 3DMark Fire Strike Score | 1517 puan | |
Yardım | ||
| 3DMark 11 - 1280x720 Performance (sort by value) | |
| HP ZBook 15u G3 | |
| Dell Precision 5510 | |
| Lenovo ThinkPad W550s 20E2-000PGE | |
| 3DMark | |
| 1920x1080 Fire Strike Score (sort by value) | |
| HP ZBook 15u G3 | |
| Dell Precision 5510 | |
| Lenovo ThinkPad W550s 20E2-000PGE | |
| HP ZBook 15 G2 | |
| 1280x720 Cloud Gate Standard Score (sort by value) | |
| HP ZBook 15u G3 | |
| Dell Precision 5510 | |
| Lenovo ThinkPad W550s 20E2-000PGE | |
| HP ZBook 15 G2 | |
| 1280x720 Ice Storm Standard Score (sort by value) | |
| HP ZBook 15u G3 | |
| Dell Precision 5510 | |
| Lenovo ThinkPad W550s 20E2-000PGE | |
| HP ZBook 15 G2 | |
| düşük | orta | yüksek | ultra | |
|---|---|---|---|---|
| BioShock Infinite (2013) | 85.2 | 38.42 | 34.08 | 13.64 |
| Rise of the Tomb Raider (2016) | 14 | 8 |
| HP ZBook 15u G3 FirePro W4190M, 6600U, Samsung SM951 MZVPV256HDGL m.2 PCI-e | Dell Precision 5510 Quadro M1000M, E3-1505M v5, SK hynix SC920 512 GB | Lenovo ThinkPad W550s 20E2-000PGE Quadro K620M, 5500U, Samsung SSD PM851 512 GB MZ7TE512HMHP | HP ZBook 15 G2 FirePro M5100, 4910MQ, SanDisk A110 SD6PP4M-256G-1006 | MSI WS60 2OJ8H11W7P Quadro K2100M, 4710HQ, Toshiba HG6 THNSNJ128G8NU | |
|---|---|---|---|---|---|
| Noise | -4% | 13% | 0% | 1% | |
| Idle Minimum * | 29.8 | 30 -1% | 26.9 10% | 30.6 -3% | 30.4 -2% |
| Idle Average * | 29.8 | 30 -1% | 26.9 10% | 30.6 -3% | 30.4 -2% |
| Idle Maximum * | 29.8 | 30 -1% | 26.9 10% | 30.6 -3% | 30.4 -2% |
| Load Average * | 39.5 | 42.08 -7% | 30.4 23% | 35.7 10% | 36.6 7% |
| Load Maximum * | 43.2 | 46.78 -8% | 38.1 12% | 43.2 -0% | 42.3 2% |
* ... smaller is better
Ses yüksekliği
| Boşta |
| 29.8 / 29.8 / 29.8 dB |
| Çalışırken |
| 39.5 / 43.2 dB |
 | ||
30 dB sessiz 40 dB(A) duyulabilirlik 50 dB(A) gürültülü |
||
min:  , med:  , max:  BK Precision 732A (15 cm uzaklık) | ||
(±) The average temperature for the upper side under maximal load is 33.9 °C / 93 F, compared to the average of 32 °C / 90 F for the devices in the class Workstation.
(±) The maximum temperature on the upper side is 44.6 °C / 112 F, compared to the average of 38.2 °C / 101 F, ranging from 22.2 to 69.8 °C for the class Workstation.
(-) The bottom heats up to a maximum of 46 °C / 115 F, compared to the average of 41.2 °C / 106 F
(+) In idle usage, the average temperature for the upper side is 23.1 °C / 74 F, compared to the device average of 32 °C / 90 F.
(+) The palmrests and touchpad are cooler than skin temperature with a maximum of 28.7 °C / 83.7 F and are therefore cool to the touch.
(±) The average temperature of the palmrest area of similar devices was 27.8 °C / 82 F (-0.9 °C / -1.7 F).
(±) The maximum temperature on the upper side is 44.6 °C / 112 F, compared to the average of 38.2 °C / 101 F, ranging from 22.2 to 69.8 °C for the class Workstation.
(-) The bottom heats up to a maximum of 46 °C / 115 F, compared to the average of 41.2 °C / 106 F
(+) In idle usage, the average temperature for the upper side is 23.1 °C / 74 F, compared to the device average of 32 °C / 90 F.
(+) The palmrests and touchpad are cooler than skin temperature with a maximum of 28.7 °C / 83.7 F and are therefore cool to the touch.
(±) The average temperature of the palmrest area of similar devices was 27.8 °C / 82 F (-0.9 °C / -1.7 F).
Anlık tüketim
| Kapalı / Bekleme modu | / 0.68 Watt |
| Boşta | 4.3 / 7.9 / 11.5 Watt |
| Çalışırken |
43.3 / 72.3 Watt |

| |
Key:
min: ,
med: ,
max: Metrahit Energy | |
| HP ZBook 15u G3 FirePro W4190M, 6600U, Samsung SM951 MZVPV256HDGL m.2 PCI-e | Dell Precision 5510 Quadro M1000M, E3-1505M v5, SK hynix SC920 512 GB | Lenovo ThinkPad W550s 20E2-000PGE Quadro K620M, 5500U, Samsung SSD PM851 512 GB MZ7TE512HMHP | HP ZBook 15 G2 FirePro M5100, 4910MQ, SanDisk A110 SD6PP4M-256G-1006 | MSI WS60 2OJ8H11W7P Quadro K2100M, 4710HQ, Toshiba HG6 THNSNJ128G8NU | |
|---|---|---|---|---|---|
| Power Consumption | -85% | 6% | -149% | -83% | |
| Idle Minimum * | 4.3 | 8.6 -100% | 4 7% | 17.1 -298% | 8.8 -105% |
| Idle Average * | 7.9 | 16.2 -105% | 9.6 -22% | 21.9 -177% | 12.4 -57% |
| Idle Maximum * | 11.5 | 16.7 -45% | 10.8 6% | 23.2 -102% | 22.4 -95% |
| Load Average * | 43.3 | 82.6 -91% | 36.9 15% | 86.6 -100% | 89 -106% |
| Load Maximum * | 72.3 | 131.8 -82% | 54.5 25% | 120.7 -67% | 111.7 -54% |
* ... smaller is better
| HP ZBook 15u G3 FirePro W4190M, 6600U, Samsung SM951 MZVPV256HDGL m.2 PCI-e | Dell Precision 5510 Quadro M1000M, E3-1505M v5, SK hynix SC920 512 GB | Lenovo ThinkPad W550s 20E2-000PGE Quadro K620M, 5500U, Samsung SSD PM851 512 GB MZ7TE512HMHP | HP ZBook 15 G2 FirePro M5100, 4910MQ, SanDisk A110 SD6PP4M-256G-1006 | MSI WS60-6QJE316H11 Quadro M2000M, E3-1505M v5, Toshiba NVMe THNSN5128GP | |
|---|---|---|---|---|---|
| Battery Runtime | -25% | 111% | -41% | -70% | |
| Reader / Idle | 756 | 428 -43% | 1728 129% | 370 -51% | 160 -79% |
| WiFi v1.3 | 312 | 286 -8% | 715 129% | 278 -11% | 106 -66% |
| Load | 141 | 109 -23% | 247 75% | 53 -62% | 51 -64% |
| H.264 | 197 | 667 | 260 | 141 | |
| WiFi | 298 | 237 |
Artılar
+ Pratik ama ilgi çekici tasarım
+ Hafif
+ Harika arayüzler
+ Boyutuna göre iyi port seçimi
+ Çift depolama alanı çözümü mümkün
+ NVMe SSD ile güçlü okuma/yazma performansı
Eksiler
- Bakım daha kolay olabilir
- Zayıf kontrast ve renk tutarlılığı
- Zayıf TN panel bakış açıları
- Bazı diğer çalışma istasyonları ile işlemci ve grafik kartı performansı yönünden rekabet edemiyor
- Full Turbo frekanslarında stress testi esnasında sürekli kalamadı
Neredeyse 1 sene önce, dha büyük HP ZBook 15 G2 oldukça yüksek bir skor olan %89 puanı almıştı. Bir yıl sonra yaklaşık %30 daha hafif ZBook 15u G3 bize cevaplardan daha çok yeni sorular bırakıyor. Elbette beğenilecek çok şey var. Ama ödünler de verilmiş. Hafiflik, düşük ses ve sıcaklık değerleri, sağlam kasa, iyi port seçimleri ve iyi sayılabilecek batarya ömrünün yanında çift çekirdekli işlemci, AMD FirePro W419M'nin performansı ve turbo frekansların sürekli yakalanamaması gibi sorunlar var. Bunun yanı sıra 1080plik ortalamanın altında kalan ekran. Bunlar belki bazı kullanıcılar için sorun olmayacak başlıklardır, ama önceki modele göre geriye dönük bir geliştirme olduğunu söyleyebiliriz.
ZBook 15u G3 ile daha ince bir yapım sunmuş olabiir ama sonuç olarak ortaya ZBook 15 G2 kadar iyi bir ürün çıktığını söylemek zor.
Bu duruma bakıldığında yine de bazı kullanıcılar için ZBook 15u G3 modelinin mantıklı olabileceğini de söylemek gerekir. Aslında fiyatı ile makul sayılabilir ve 3 yıl garantisi de mevcut. Bunun üstüne herkes çok güçlü bir işlemci ve grafik kartına ihtiyaç duymuyor. Bütçesine uygun bir cihaz arayanlar için oldukça uygun olabilir.
Yazının orjinali için tıklayın.
HP ZBook 15u G3
-
03/07/2016 v5 (old)
Steve Schardein
Workstation - Ortalama Ağırlık
