Kısa inceleme: Lenovo ThinkPad X260 (Core i5, WXGA) Notebook
Lenovo ThinkPad X260-20F60041GE (ThinkPad X260 Seri)
İşlemci
Intel Core i5-6200U 2 x 2.3 - 2.8 GHz, Skylake, 2 cores, TDP: 15 W
Grafik kartı
Intel HD Graphics 520, Çekirdek: 1000 MHz, 20.19.15.4331
Bellek
4 GB
, DDR4-2133, 1/1 Slots occupied
Görüntü
12.50 inç 16:9, 1366 x 768 pixel, LEN40E5 M125NWR3 R0, IPS, parlak: hayır
Anakart
Intel Skylake-U Premium PCH
Harddisk
Seagate ST500LM000 Solid State Hybrid Drive, 500 GB
, 5400 rpm
Ağırlık
1.505 kg, Güç kaynağı: 290 g
Fiyat
1460 Euro
Bağlantılar
Note: The manufacturer may use components from different suppliers including display panels, drives or memory sticks with similar specifications.
| |||||||||||||||||||||||||
LEN40E5 M125NWR3 R0 tested with X-Rite i1Pro 2
Maksimum: 262 cd/m² (Nits) Ortalama: 251.1 cd/m² Minimum: 4 cd/m²Aydınlatma: 88 %
Batarya modunda parlaklık: 264 cd/m²
Kontrast: 1008:1 (Siyah: 0.26 cd/m²)
ΔE Color 3.55 | 0.5-29.43 Ø4.92
ΔE Greyscale 3.36 | 0.5-98 Ø5.2
72.4% sRGB (Calman 2D)
45.9% AdobeRGB 1998 (Argyll 1.6.3 3D)
49.79% AdobeRGB 1998 (Argyll 2.2.0 3D)
72.6% sRGB (Argyll 2.2.0 3D)
48.19% Display P3 (Argyll 2.2.0 3D)
Gamma: 2.39
| Lenovo ThinkPad X260-20F60041GE HD Graphics 520, 6200U, Seagate ST500LM000 Solid State Hybrid Drive | Dell Latitude 12 E7250 HD Graphics 5500, 5300U, Samsung PM851 Series MZMTE256HMHP | HP Elitebook 820 G2-J8R58EA HD Graphics 5500, 5500U, Samsung SSD PM851 256 GB MZ7TE256HMHP | Lenovo ThinkPad X250-20CLS06D00 HD Graphics 5500, 5600U, Intel SSD Pro 2500 Series SSDSC2BF360A5L | |
|---|---|---|---|---|
| Display | -8% | -9% | -8% | |
| Display P3 Coverage | 48.19 | 44.48 -8% | 43.72 -9% | 44.14 -8% |
| sRGB Coverage | 72.6 | 66.2 -9% | 65.3 -10% | 65.8 -9% |
| AdobeRGB 1998 Coverage | 49.79 | 45.96 -8% | 45.24 -9% | 45.71 -8% |
| Response Times | ||||
| Response Time Grey 50% / Grey 80% * | 42.8 ? | |||
| Response Time Black / White * | 27.2 ? | |||
| PWM Frequency | 220 ? | |||
| Screen | -20% | 1% | -2% | |
| Brightness middle | 262 | 360 37% | 300 15% | 397 52% |
| Brightness | 251 | 330 31% | 298 19% | 357 42% |
| Brightness Distribution | 88 | 81 -8% | 83 -6% | 81 -8% |
| Black Level * | 0.26 | 0.53 -104% | 0.33 -27% | 0.44 -69% |
| Contrast | 1008 | 679 -33% | 909 -10% | 902 -11% |
| Colorchecker dE 2000 * | 3.55 | 5.58 -57% | 3.68 -4% | 4.2 -18% |
| Colorchecker dE 2000 max. * | 5.85 | |||
| Greyscale dE 2000 * | 3.36 | 3.98 -18% | 2.47 26% | 3.1 8% |
| Gamma | 2.39 92% | 2.21 100% | 2.4 92% | 2.6 85% |
| CCT | 5985 109% | 6192 105% | 6310 103% | 6246 104% |
| Color Space (Percent of AdobeRGB 1998) | 45.9 | 42.2 -8% | 41.6 -9% | 42 -8% |
| Color Space (Percent of sRGB) | 64.9 | 65.5 | ||
| Total Average (Program / Settings) | -14% /
-17% | -4% /
-2% | -5% /
-3% |
* ... smaller is better
Display Response Times
ℹ
Display response times show how fast the screen is able to change from one color to the next. Slow response times can lead to afterimages and can cause moving objects to appear blurry (ghosting). Gamers of fast-paced 3D titles should pay special attention to fast response times.| ↔ Response Time Black to White | ||
|---|---|---|
| 27.2 ms ... rise ↗ and fall ↘ combined | ↗ 12.4 ms rise |  |
| ↘ 14.8 ms fall | ||
| The screen shows relatively slow response rates in our tests and may be too slow for gamers. In comparison, all tested devices range from 0.1 (minimum) to 240 (maximum) ms. » 66 % of all devices are better. This means that the measured response time is worse than the average of all tested devices (21 ms). | ||
| ↔ Response Time 50% Grey to 80% Grey | ||
| 42.8 ms ... rise ↗ and fall ↘ combined | ↗ 18.8 ms rise |  |
| ↘ 24 ms fall | ||
| The screen shows slow response rates in our tests and will be unsatisfactory for gamers. In comparison, all tested devices range from 0.165 (minimum) to 636 (maximum) ms. » 68 % of all devices are better. This means that the measured response time is worse than the average of all tested devices (32.9 ms). | ||
Screen Flickering / PWM (Pulse-Width Modulation)
ℹ
To dim the screen, some notebooks will simply cycle the backlight on and off in rapid succession - a method called Pulse Width Modulation (PWM) . This cycling frequency should ideally be undetectable to the human eye. If said frequency is too low, users with sensitive eyes may experience strain or headaches or even notice the flickering altogether.| Screen flickering / PWM detected | 220 Hz | ≤ 90 % brightness setting |  |
The display backlight flickers at 220 Hz (worst case, e.g., utilizing PWM) Flickering detected at a brightness setting of 90 % and below. There should be no flickering or PWM above this brightness setting. The frequency of 220 Hz is relatively low, so sensitive users will likely notice flickering and experience eyestrain at the stated brightness setting and below. In comparison: 53 % of all tested devices do not use PWM to dim the display. If PWM was detected, an average of 8743 (minimum: 5 - maximum: 343500) Hz was measured. | |||
| Lenovo ThinkPad X260-20F60041GE HD Graphics 520, 6200U, Seagate ST500LM000 Solid State Hybrid Drive | Dell Latitude 12 E7250 HD Graphics 5500, 5300U, Samsung PM851 Series MZMTE256HMHP | HP Elitebook 820 G2-J8R58EA HD Graphics 5500, 5500U, Samsung SSD PM851 256 GB MZ7TE256HMHP | Lenovo ThinkPad X250-20CLS06D00 HD Graphics 5500, 5600U, Intel SSD Pro 2500 Series SSDSC2BF360A5L | |
|---|---|---|---|---|
| PCMark 7 | ||||
| Score | 3777 | 4662 23% | 4414 17% | 4609 22% |
| PCMark 8 | -17% | -8% | -3% | |
| Home Score Accelerated v2 | 3262 | 2772 -15% | 2987 -8% | 3148 -3% |
| Creative Score Accelerated v2 | 3735 | 3052 -18% | 3306 -11% | 3458 -7% |
| Work Score Accelerated v2 | 4335 | 4133 -5% | 4345 0% | |
| Total Average (Program / Settings) | 3% /
-3% | 5% /
-2% | 10% /
3% |
| PCMark 7 Score | 3777 puan | |
| PCMark 8 Home Score Accelerated v2 | 3262 puan | |
| PCMark 8 Creative Score Accelerated v2 | 3735 puan | |
| PCMark 8 Work Score Accelerated v2 | 4335 puan | |
Yardım | ||
| Lenovo ThinkPad X260-20F60041GE HD Graphics 520, 6200U, Seagate ST500LM000 Solid State Hybrid Drive | Dell Latitude 12 E7250 HD Graphics 5500, 5300U, Samsung PM851 Series MZMTE256HMHP | HP Elitebook 820 G2-J8R58EA HD Graphics 5500, 5500U, Samsung SSD PM851 256 GB MZ7TE256HMHP | Lenovo ThinkPad X250-20CLS06D00 HD Graphics 5500, 5600U, Intel SSD Pro 2500 Series SSDSC2BF360A5L | |
|---|---|---|---|---|
| CrystalDiskMark 3.0 | 6400% | 9973% | 3648% | |
| Read Seq | 107.9 | 509 372% | 523 385% | 419.8 289% |
| Write Seq | 110.2 | 244 121% | 268.3 143% | 228.6 107% |
| Read 512 | 36.26 | 428 1080% | 445.6 1129% | 355.2 880% |
| Write 512 | 77.1 | 244 216% | 268.1 248% | 203.3 164% |
| Read 4k | 0.497 | 29 5735% | 29.14 5763% | 27.86 5506% |
| Write 4k | 3.136 | 61 1845% | 136.4 4249% | 15.3 388% |
| Read 4k QD32 | 1.155 | 214 18428% | 384.3 33173% | 163.9 14090% |
| Write 4k QD32 | 0.766 | 180 23399% | 266.5 34691% | 60.2 7759% |
Seagate ST500LM000 Solid State Hybrid Drive
Maksimum transfer hızı:
9 MB/s
Minimum transfer hızı:
110.7 MB/s
Ortlama transfer hızı:
83.6 MB/s
Erişim hızı:
18.2 ms
Yakma hızı:
144 MB/s
İşlemci kullanımı:
7.6 %
| 3DMark 11 - 1280x720 Performance | |
| Dell XPS 13-9350 | |
| Acer Aspire R13 R7-372T | |
| Asus Zenbook UX303UA-FN121T | |
| Lenovo ThinkPad X260-20F60041GE | |
| HP ProBook 440 G3 PL | |
| Lenovo ThinkPad X250-20CLS06D00 | |
| HP Elitebook 820 G2-J8R58EA | |
| Dell Latitude 12 E7250 | |
| 3DMark 11 Performance | 1332 puan | |
| 3DMark Ice Storm Standard Score | 45479 puan | |
| 3DMark Cloud Gate Standard Score | 4938 puan | |
| 3DMark Fire Strike Score | 688 puan | |
Yardım | ||
| Tomb Raider | |
| 1366x768 Normal Preset AA:FX AF:4x | |
| HP Envy 13-d000ng | |
| HP ProBook 430 G3 P5T00ES | |
| Acer Aspire R13 R7-372T | |
| Asus Zenbook UX303UA-FN121T | |
| HP ProBook 440 G3 | |
| Lenovo ThinkPad X260-20F60041GE | |
| Lenovo ThinkPad X250-20CLS06D00 | |
| HP Elitebook 820 G2-J8R58EA | |
| Dell Latitude 12 E7250 | |
| 1366x768 High Preset AA:FX AF:8x | |
| HP ProBook 430 G3 P5T00ES | |
| HP Envy 13-d000ng | |
| Acer Aspire R13 R7-372T | |
| Asus Zenbook UX303UA-FN121T | |
| Lenovo ThinkPad X260-20F60041GE | |
| Dell Latitude 12 E7250 | |
| Lenovo ThinkPad X250-20CLS06D00 | |
| HP ProBook 440 G3 | |
| HP Elitebook 820 G2-J8R58EA | |
| 1024x768 Low Preset | |
| HP Envy 13-d000ng | |
| HP ProBook 430 G3 P5T00ES | |
| Acer Aspire R13 R7-372T | |
| Asus Zenbook UX303UA-FN121T | |
| HP ProBook 440 G3 | |
| Lenovo ThinkPad X260-20F60041GE | |
| Lenovo ThinkPad X250-20CLS06D00 | |
| HP Elitebook 820 G2-J8R58EA | |
| Dell Latitude 12 E7250 | |
| düşük | orta | yüksek | ultra | |
|---|---|---|---|---|
| Tomb Raider (2013) | 48.3 | 25.5 | 16.8 | 9.6 |
| BioShock Infinite (2013) | 33.13 | 20.1 | 16.74 | 5.1 |
| Battlefield 4 (2013) | 34.7 | 24.1 | 14 | 4.1 |
Ses yüksekliği
| Boşta |
| 29.4 / 29.4 / 29.4 dB |
| HDD |
| 29.6 dB |
| Çalışırken |
| 33.2 / 33.2 dB |
 | ||
30 dB sessiz 40 dB(A) duyulabilirlik 50 dB(A) gürültülü |
||
min:  , med:  , max:  Voltcraft SL-451 + Behringer ECM8000 (15 cm uzaklık) environment noise: 29 dB(A) | ||
(+) The average temperature for the upper side under maximal load is 30.9 °C / 88 F, compared to the average of 30.8 °C / 87 F for the devices in the class Subnotebook.
(-) The maximum temperature on the upper side is 45.3 °C / 114 F, compared to the average of 35.9 °C / 97 F, ranging from 21.4 to 59 °C for the class Subnotebook.
(-) The bottom heats up to a maximum of 48.8 °C / 120 F, compared to the average of 39.4 °C / 103 F
(+) In idle usage, the average temperature for the upper side is 26.7 °C / 80 F, compared to the device average of 30.8 °C / 87 F.
(+) The palmrests and touchpad are cooler than skin temperature with a maximum of 27.9 °C / 82.2 F and are therefore cool to the touch.
(±) The average temperature of the palmrest area of similar devices was 28.3 °C / 82.9 F (+0.4 °C / 0.7 F).
(-) The maximum temperature on the upper side is 45.3 °C / 114 F, compared to the average of 35.9 °C / 97 F, ranging from 21.4 to 59 °C for the class Subnotebook.
(-) The bottom heats up to a maximum of 48.8 °C / 120 F, compared to the average of 39.4 °C / 103 F
(+) In idle usage, the average temperature for the upper side is 26.7 °C / 80 F, compared to the device average of 30.8 °C / 87 F.
(+) The palmrests and touchpad are cooler than skin temperature with a maximum of 27.9 °C / 82.2 F and are therefore cool to the touch.
(±) The average temperature of the palmrest area of similar devices was 28.3 °C / 82.9 F (+0.4 °C / 0.7 F).
Anlık tüketim
| Kapalı / Bekleme modu | 0.18 / 0.3 Watt |
| Boşta | 3.6 / 5.9 / 6.6 Watt |
| Çalışırken |
28.5 / 36.8 Watt |

| |
Key:
min: ,
med: ,
max: Metrahit Energy | |
| Battery Runtime - WiFi Websurfing | |
| Lenovo ThinkPad X260-20F60041GE | |
| HP Elitebook 820 G2-J8R58EA | |
| Lenovo ThinkPad X250-20CLS06D00 | |
Artılar
+ Klavye
+ Hızlı değiştirilebilir batarya
+ Sağlam yapım
+ Güvenlik özellikleri
Eksiler
- Yapım kalitesi sorunları
- Bakım kapağı yok
- Sadece tek kanallı bellek
"İş için optimize edildi." Lenovo, yeni ThinkPad X260 modeli için bu sözleri kullanıyor. Bu sözün bürçok alanda doğru olduğunu söyleyebiliriz. Kasası özellikle tam bu sözü doğrular nitelikte. Bu sınıftaki notebooklar ofis uygulamaları için özellikle tasarlanıyor ve Lenovo bu beklentiyi bir adım ileri taşıyor. Bazı ufak şeyler dışında klavye bir ofis cihazından beklediğimiz gibi.
IPS ekran mat yüzeyi ve iyi resim kalitesiyle tatmin ediyor. Çözünürlük ise malesef düşük ve parlaklık sadece ortalama.
Cihazın içine bakında sağlam bir donanım görüyoruz. Ancak malesef sadece bir adet DDR4 slotu mevcut ve bu yüzden tek kanallı bellek kullanabiliyorsunuz. Genel olarak ise sistem performansı tatmin edici. Daha fazla performansa ihtiyaç duyarsanız daha üst modelleri de mevcut. İki bataryanın kullanılması sayesinde de bataryalardan birini çalışırken değiştirmeniz mümkün.
Lenovo sağlam bir 12.5 inçlik iş laptopu sunuyor. Test cihazımız bazı noktalarda sorun yaşasa da, diğer modellerinin daha iyi bir sonuç verip vermeyeceğini göreceğiz.
Yazının orjinali için tıklayın.
Lenovo ThinkPad X260-20F60041GE
- 03/10/2016 v5 (old)
Nino Ricchizzi
