Kısa inceleme: Microsoft Surface 3 Tablet/dönüştürülebilir

"Notebook-Öldüren" Vol. 3 - Surface Pro 3 modelinden sonra Microsoft, Surface 3 ile daha makul bit model sunuyor.

J. Simon Leitner, Klaus A. Hinum, Published 05/08/2015 🇺🇸 🇩🇪 ...

Microsoft Surface 3 (Surface Seri)

İşlemci

Intel Atom x7-Z8700 4 x 1.6 - 2.4 GHz, Cherry Trail

Grafik kartı

Intel HD Graphics (Cherry Trail)

Bellek

4 GB

Görüntü

10.80 inç 3:2, 1920 x 1280 pixel, 10-point multi-touch, native pen support, Panasonic MEI9001, IPS, parlak: evet, detachable screen

Harddisk

128 GB eMMC Flash, 128 GB

, 93.2 GB Boş

Bağlantılar

1 USB 2.0, 1 USB 3.0, 1 DisplayPort, Ses çıkışları: combined 3.5 headset, Kart okuyucular: microSD card reader, Brightness Sensor, Alıcılar: Ambient light sensor, proximity sensor, accelerometer, gyroscope, magnetometer, Micro-USB charging port

Network

802.11 a/b/g/n/ac (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 4.0

Boyut

yükseklik x genişlik x derinlik (mm): 8.7 x 267 x 187

Batarya

28 Wh, Batarya kullanım süresi (üreticiye göre): 10 h

İşletim sistemi

Microsoft Windows 8.1 64 Bit

Camera

Webcam: 3.5 MP webcam, 8.0 MP rear camera
Primary Camera: 8 MPix
Secondary Camera: 3.5 MPix

Ek özellikler

Hoparlörler: Stereo with Dolby Audio, Klavye: optional type cover, Klavye ışığı: hayır, Office 365 Personal (1 year), 24 Ay Garanti, fanless

Ağırlık

917 g, Güç kaynağı: 168 g

Fiyat

719 Euro

Note: The manufacturer may use components from different suppliers including display panels, drives or memory sticks with similar specifications.

see all specifications

In Comparison

Microsoft Surface Pro 3 Microsoft Surface 2 Microsoft Surface 3 Apple iPad Air 2 2014 DIN A4 ❌


366 cd/m²	404 cd/m²	390 cd/m²
373 cd/m²	399 cd/m²	373 cd/m²
363 cd/m²	374 cd/m²	374 cd/m²

Parlaklığın yayılımı

Panasonic MEI9001 tested with X-Rite i1Pro 2

Maksimum: 404 cd/m² (Nits) Ortalama: 379.6 cd/m²
Aydınlatma: 90 %
Batarya modunda parlaklık: 399 cd/m²
Kontrast: 814:1 (Siyah: 0.49 cd/m²)
ΔE Color 1.66 | 0.5-29.43 Ø4.93
ΔE Greyscale 2.75 | 0.5-98 Ø5.2
98.8% sRGB (Argyll 1.6.3 3D)
64.4% AdobeRGB 1998 (Argyll 1.6.3 3D)
70.4% AdobeRGB 1998 (Argyll 2.2.0 3D)
98.7% sRGB (Argyll 2.2.0 3D)
68.8% Display P3 (Argyll 2.2.0 3D)
Gamma: 2.22

Download ICC Dosyası (X-Rite i1Pro 2)

	Microsoft Surface 3 HD Graphics (Cherry Trail), Z8700, 128 GB eMMC Flash	Microsoft Surface Pro 3 HD Graphics 4400, 4300U, Hynix HFS128G3MNM	Microsoft Surface 2 GeForce Tegra 4, 4, 32 GB eMMC Flash	Apple iPad Air 2 2014 PowerVR GXA6850, A8X, 128 GB eMMC Flash
Screen		-36%	-22%	-5%
Brightness middle	399	355.3 -11%	357 -11%	423 6%
Brightness	380	338 -11%	369 -3%	427 12%
Brightness Distribution	90	91 1%	89 -1%	92 2%
Black Level *	0.49	0.33 33%	0.51 -4%	0.61 -24%
Contrast	814	1077 32%	700 -14%	693 -15%
Colorchecker dE 2000 *	1.66	4.72 -184%	3.86 -133%	2.86 -72%
Colorchecker dE 2000 max. *	3.24
Greyscale dE 2000 *	2.75	6.53 -137%	2.4 13%	2.37 14%
Gamma	2.22 ^99%	2.17 ^101%	2.46 ^89%	2.43 ^91%
CCT	6358 ^102%	6707 ^97%	6740 ^96%	6941 ^94%
Color Space (Percent of AdobeRGB 1998)	64.4	59.37 -8%		88 37%
Color Space (Percent of sRGB)	98.8

* ... smaller is better

Cinebench R11.5
CPU Single 64Bit (sort by value)
Microsoft Surface 3, Z8700	0.46 Points
HP ElitePad 1000 G2, Z3795	0.44 Points -4%
Toshiba Satellite W30t-A-101, 4020Y	0.67 Points +46%
Microsoft Surface Pro 3, 4300U	1.12 Points +143%
CPU Multi 64Bit (sort by value)
Microsoft Surface 3, Z8700	1.79 Points
HP ElitePad 1000 G2, Z3795	1.64 Points -8%
Toshiba Satellite W30t-A-101, 4020Y	1.63 Points -9%
Microsoft Surface Pro 3, 4300U	2.77 Points +55%

Cinebench R15
CPU Single 64Bit (sort by value)
Microsoft Surface 3, Z8700	38 Points
HP ElitePad 1000 G2, Z3795	36 Points -5%
Toshiba Satellite W30t-A-101, 4020Y	60 Points +58%
CPU Multi 64Bit (sort by value)
Microsoft Surface 3, Z8700	134 Points
HP ElitePad 1000 G2, Z3795	134 Points 0%
Toshiba Satellite W30t-A-101, 4020Y	152 Points +13%

Cinebench R10
Rendering Single 32Bit (sort by value)
Microsoft Surface 3, Z8700	1225 Points
Fujitsu Stylistic Q584, Z3770	997 Points -19%
HP Omni 10 5600eg (F4W59EA), Z3770	1230 Points 0%
HP ElitePad 1000 G2, Z3795	1234 Points +1%
Toshiba Satellite W30t-A-101, 4020Y	2241 Points +83%
Microsoft Surface Pro 3, 4300U	3675 Points +200%
Rendering Multiple CPUs 32Bit (sort by value)
Microsoft Surface 3, Z8700	4356 Points
Fujitsu Stylistic Q584, Z3770	2848 Points -35%
HP Omni 10 5600eg (F4W59EA), Z3770	3939 Points -10%
HP ElitePad 1000 G2, Z3795	4106 Points -6%
Toshiba Satellite W30t-A-101, 4020Y	5004 Points +15%
Microsoft Surface Pro 3, 4300U	7067 Points +62%

X264 HD Benchmark 4.0
Pass 1 (sort by value)
Microsoft Surface 3, Z8700	50.8 fps
HP ElitePad 1000 G2, Z3795	47.13 fps -7%
Toshiba Satellite W30t-A-101, 4020Y	52.2 fps +3%
Microsoft Surface Pro 3, 4300U	75.5 fps +49%
Pass 2 (sort by value)
Microsoft Surface 3, Z8700	10.28 fps
HP ElitePad 1000 G2, Z3795	9.5 fps -8%
Toshiba Satellite W30t-A-101, 4020Y	9.6 fps -7%
Microsoft Surface Pro 3, 4300U	13.47 fps +31%

Super Pi mod 1.5 XS 1M - 1M (sort by value)
Microsoft Surface 3, Z8700	49.78 s *
HP Omni 10 5600eg (F4W59EA), Z3770	27 s * +46%
HP ElitePad 1000 G2, Z3795	36.26 s * +27%
Toshiba Satellite W30t-A-101, 4020Y	24.81 s * +50%
Microsoft Surface Pro 3, 4300U	13 s * +74%

Super Pi mod 1.5 XS 2M - 2M (sort by value)
Microsoft Surface 3, Z8700	96.7 s *
HP Omni 10 5600eg (F4W59EA), Z3770	61 s * +37%
HP ElitePad 1000 G2, Z3795	79.6 s * +18%
Toshiba Satellite W30t-A-101, 4020Y	54.9 s * +43%
Microsoft Surface Pro 3, 4300U	30 s * +69%

wPrime 2.10 - 32m (sort by value)
Microsoft Surface 3, Z8700	24.51 s *
HP Omni 10 5600eg (F4W59EA), Z3770	24 s * +2%
HP ElitePad 1000 G2, Z3795	25.93 s * -6%
Toshiba Satellite W30t-A-101, 4020Y	35.31 s * -44%
Microsoft Surface Pro 3, 4300U	19.9 s * +19%

Legend

Microsoft Surface 3 Intel Atom x7-Z8700, Intel HD Graphics (Cherry Trail), 128 GB eMMC Flash

Fujitsu Stylistic Q584 Intel Atom Z3770, Intel HD Graphics (Bay Trail), 128 GB eMMC Flash

HP Omni 10 5600eg (F4W59EA) Intel Atom Z3770, Intel HD Graphics (Bay Trail), 32 GB eMMC Flash

HP ElitePad 1000 G2 Intel Atom Z3795, Intel HD Graphics (Bay Trail), 128 GB eMMC Flash

Toshiba Satellite W30t-A-101 Intel Core i3-4020Y, Intel HD Graphics 4200, WD Blue UltraSlim WD5000MPCK-22AWHT0

Microsoft Surface Pro 3 Intel Core i5-4300U, Intel HD Graphics 4400, Hynix HFS128G3MNM

* ... smaller is better

	Microsoft Surface 3 128 GB eMMC Flash	Microsoft Surface Pro 3 Hynix HFS128G3MNM	Dell Venue 11 Pro 7140 Sandisk X110 M.2 SD6SP1M-128G	Lenovo ThinkPad Helix 2 Toshiba THNSFJ256GDNU 256 GB	Acer Aspire Switch 11 SW5-171-31U3 Lite-On IT L8T-64L9G	Acer Aspire Switch 10 SW5-012-13DP 32 GB eMMC Flash	Lenovo ThinkPad Yoga 12 Seagate ST500LM000 Solid State Hybrid Drive
CrystalDiskMark 3.0		765%	417%	447%	409%	14%	-49%
Read Seq	149.3	501 236%	395.6 165%	422.7 183%	504 238%	169.3 13%	33.57 -78%
Write Seq	47.99	324 575%	221.9 362%	247.4 416%	167.2 248%	72.8 52%	107.6 124%
Read 512	133.7	357.8 168%	209.1 56%	333.7 150%	378.7 183%	151.1 13%	29.68 -78%
Write 512	39.9	324.6 714%	153.5 285%	164.9 313%	167.2 319%	72.7 82%	47.23 18%
Read 4k	12.64	20.81 65%	22.9 81%	19.44 54%	29.46 133%	18.31 45%	0.351 -97%
Write 4k	9.52	76.2 700%	35.29 271%	43.08 353%	57.6 505%	5.603 -41%	0.64 -93%
Read 4k QD32	27.94	345 1135%	256.4 818%	295.9 959%	195 598%	26.66 -5%	0.706 -97%
Write 4k QD32	11.2	294.4 2529%	156.1 1294%	139.3 1144%	128.1 1044%	5.642 -50%	0.665 -94%

3DMark 11 | Cinebench R11.5 | Cinebench R15 | Cinebench R10

3DMark 11 - 1280x720 Performance (sort by value)
Microsoft Surface 3, Z8700, HD Graphics (Cherry Trail)	562 Points
Fujitsu Stylistic Q584, Z3770, HD Graphics (Bay Trail)	207 Points -63%
HP Omni 10 5600eg (F4W59EA), Z3770, HD Graphics (Bay Trail)	202 Points -64%
HP ElitePad 1000 G2, Z3795, HD Graphics (Bay Trail)	233 Points -59%
Toshiba Satellite W30t-A-101, 4020Y, HD Graphics 4200	828 Points +47%
Microsoft Surface Pro 3, 4300U, HD Graphics 4400	877 Points +56%

Cinebench R11.5 - OpenGL 64Bit (sort by value)
Microsoft Surface 3, Z8700, HD Graphics (Cherry Trail)	11.71 fps
HP ElitePad 1000 G2, Z3795, HD Graphics (Bay Trail)	6.74 fps -42%
Toshiba Satellite W30t-A-101, 4020Y, HD Graphics 4200	18.78 fps +60%
Microsoft Surface Pro 3, 4300U, HD Graphics 4400	19.48 fps +66%

Cinebench R15
OpenGL 64Bit (sort by value)
Microsoft Surface 3, Z8700, HD Graphics (Cherry Trail)	14.71 fps
HP ElitePad 1000 G2, Z3795, HD Graphics (Bay Trail)	5.1 fps -65%
Ref. Match 64Bit (sort by value)
Microsoft Surface 3, Z8700, HD Graphics (Cherry Trail)	98 %
HP ElitePad 1000 G2, Z3795, HD Graphics (Bay Trail)	97.8 % 0%

Cinebench R10 - Shading 64Bit (sort by value)
HP ElitePad 1000 G2, Z3795, HD Graphics (Bay Trail)	2304 Points
Toshiba Satellite W30t-A-101, 4020Y, HD Graphics 4200	4471 Points
Microsoft Surface Pro 3, 4300U, HD Graphics 4400	7154 Points

Legend

Microsoft Surface 3 Intel Atom x7-Z8700, Intel HD Graphics (Cherry Trail), 128 GB eMMC Flash

Fujitsu Stylistic Q584 Intel Atom Z3770, Intel HD Graphics (Bay Trail), 128 GB eMMC Flash

HP Omni 10 5600eg (F4W59EA) Intel Atom Z3770, Intel HD Graphics (Bay Trail), 32 GB eMMC Flash

HP ElitePad 1000 G2 Intel Atom Z3795, Intel HD Graphics (Bay Trail), 128 GB eMMC Flash

Toshiba Satellite W30t-A-101 Intel Core i3-4020Y, Intel HD Graphics 4200, WD Blue UltraSlim WD5000MPCK-22AWHT0

Microsoft Surface Pro 3 Intel Core i5-4300U, Intel HD Graphics 4400, Hynix HFS128G3MNM

Batarya ömrü

Boşta (WLAN kapalı, minimum parlaklık)		13h 48min
WLAN açıkken		7h 05min
WiFi Websurfing		7h 17min
Çalışırken (maksimum parlaklık)		2h 53min

	Microsoft Surface 3 Z8700, 28 Wh	Microsoft Surface Pro 3 4300U, 42 Wh	Dell Venue 11 Pro 7140 5Y10a, 38 Wh	Lenovo ThinkPad Helix 2 5Y71, 35 Wh	Acer Aspire Switch 11 SW5-171-31U3 4012Y, 32 Wh	Acer Aspire Switch 10 SW5-012-13DP Z3735F, 24 Wh	Lenovo ThinkPad Yoga 12 5200U, 47 Wh	MSI S100 Z3740D, 27 Wh	Lenovo ThinkPad Yoga 11e 20D9000QGE N2930, 34 Wh
Battery Runtime		8%	22%	8%	-22%	7%	-12%	-17%	-32%
Reader / Idle	828	1096 32%	777 -6%	964 16%			788 -5%	720 -13%
WiFi	425	504 19%	562 32%	396 -7%	331 -22%	453 7%	433 2%	340 -20%
WiFi v1.3	437								297 -32%
Load	173	124 -28%	244 41%	197 14%			117 -32%
H.264				360				330

Microsoft Surface 3 modelinin iyi bir paket olduğundan bahsetmiştik. Ortada gözle görünebilen ve eleştirilebilecek bir sorun gözükmüyor. Kasa ve yapım kalitesi önceki versiyonu gibi gayet iyi. Yazım kılıfı ile uzun yazım işlemleri kolaylaştırılabilir. Renkler ve aydınlatma da iyi seviyede.

The Surface 3 closes the gap between a tablet and a notebook like we have never seen before. We are eager to follow the journey of Surface products over the next couple of years.

Surface 3 modeli tablet ve notebook arasındaki farkı daha önce hiç görmediğimiz kadar kapartıyor. Surface modellerinin önümüzdeki yıllarda nasıl gelişeceğini merakla bekliyoruz.
